4000L Chemical Dosing Equipment
Dagyee DT4165 4000 Capacity Mixer Chamber Chemical Dosing System For Rejuvenating Mature Fields
DAGYEE all in one polymer preparation system is used for the dosing of liquid powder flocculants. It can be widely used in water treatment applications in wastewater, papermaking, chemical, petrochemical and mineral processing industries.
This device is an automatic and continuous powder dispensing and dosing system.The dry powder enters the premix and water from the screw at the bottom of the hopper for premix, and the wet material enters the mixing tank for dilution and mixing, and is prepared according to the concentration required by the user.
The preparation solution goes from the preparation tank to the curing tank and then into the storage tank. When the liquid level of the storage tank is at a high level, the preparation process will automatically stop, and when the solution drops to a low level, the batching process will automatically start.Agitator is set in both preparation tank and curing tank to ensure the dilution and curing of reagents.The prepared flow rate and concentration can be determined by adjusting the inlet flow rate and the rotating speed of the screw shaft.
| Model | DT4165 |
| Capacity(L/h) | 4000 |
| Power(kw) | 3.2 |
| Powder dosage(kg/h) | 3.5-4.5 |
| Water inlet flow(m3/h) | 2.4-12 |
| L(mm) | 2780 |
| B(mm) | 1440 |
| H(mm) | 2250 |
| L1(mm) | 2700 |
| B1(mm) | 1390 |
| Net weight(kg) | 1050 |
The Feature Of Dissolver Dosing Device
- Fully-automatic operation saves manpower
- Accurate quantitative-dosing avoids chemicals waste
- Empty-load & over-flow protection during operation
- Highly efficient mixing system
- Special powder immersing & heating system avoids caking and uneven-dissolving problems
The Application Of Dissolver Dosing Device
- Related products
- Screening Microscreen Rotating Drum Filter
- Filtering Self-Cleaning Filter
- FlocculationAuto-dosing Device
- Volute Screw Sludge Dewatering Machine
- Horizontal Decanter Centrifuge
