Air Compressor ST-300 Pneumatic Well Drilling Rig
300m Air Compressor Pneumatic Bore Well Drilling Machine ST-300
Pneumatic Water Well Drilling Rig Brief Introduction
FL series bore well drilling machine is a type of light, high efficient and multifunctional drilling rig. It is widely applied in water well, irrigation well or other boreholes, especially good for mountain areas or rock foundations. The drilling rig adopts new hydraulic technology, supporting high-torque hydraulic motor rotation and large-bore hydraulic cylinder propulsion.
The Main Parameters
|
Weight of whole machine
|
7T
|
|
Drilling caliber
|
140-325mm
|
|
Drilling depth
|
300m
|
|
One-time push length
|
3.4m
|
|
Walking speed
|
2.5km/h
|
|
Climbing ability
|
Max. 30
|
|
Power of main machine
|
75.8kw
|
|
Working pressure
|
1.7-3.0mpa
|
|
Air consumption
|
17-35m3/min
|
|
Diameter of drill rod
|
76, 89, 102mm
|
|
Length of drill rod
|
1.5, 2.0, 3.0m
|
|
Lifting force
|
18T
|
|
Rotation speed
|
40-70rpm
|
|
Rotation torque
|
5700-7500N.m
|
|
Dimension
|
4100*1950*2600mm
|
Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：
Pneumatic Drilling Rig / Air Drilling Rig（ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter
OEM / ODM can accept. Good quality, professional after-sales service, welcome to order
