Xy-1a Hydraulic Small Rotary Drilling Rig Machine For 150 Meters Depth
XY-1A Small Hydraulic Drilling Machine 150 Meters Detph Crawler Mounted Drilling Rig
XY-1A Crawler Mounted Drilling Rig Information
XY-1 A drilling rig is a light drill for shallow hole with a hydraulic feeding. It is efficient and convenient, designed by our company to meet the requirements of modern geological and engineering operations, and the feedback of our customers all over the world has been positive.
XY-1A Crawler Mounted Drilling Rig Tech Data
| Drill | Swivel Head | ||
|
Drilling depth
|
Max.150m |
Spindle speed
|
1010,790,470,295,140(r/min) |
|
Hole diameter
|
Max.150m | Spindle stroke | 450kmm |
| Drill rod diameter | 42mm | Spindle pull-down | Max.15KN |
| Angle range | 90-75 | Spindle lifting capacity | Max. 25KN |
| Oil pump | Water pump | ||
| Model | YBC-12/125 | Model | Horizontal reciprocating single-acting piston pump |
| Rated pressure | 12.5Mpa | Working pressure | Max. 1.25Mpa |
| Flow speed | 8ml/r | ||
| Rated speed | 1500r/min | ||
| Hoist | Power(diesel) | ||
| Max. lifting capacity | 15KN | Model(diesel engine | ZS1105 |
| Hoisting drum revolution |
121,76,36(r/min)
|
Rated power | 12.1KW |
| Drum diameter | 140mm | Rated speed | 2200r/m |
| WEIGHT | AROUND 600KG | ||
| SIZE | 1620*970*1560mm | ||
XY-1A Crawler Mounted Drilling Rig Advantages
XY-1A High Speed Core Drilling Rig
a. five gears, and the highest speed can reach 1045r/min, improving drill efficiency
b. 53 x 59 drilling rod adopted, high rigidity and strong delivery torque.
c. the machine is equipped with national patent technology---taper clutch, with charactristics of strong transmission troque, easy operation and free maintenance.
d. for the winch, we use large module planetary gear and add supporting frame, greatly increasing hoisting and braking ability of the winch.
e. Vertical spidle are fixed by four groups of bearings to ensure that the rotary machine is rigid enough for gravel layer and other complex geoloical conditions.
