In the competitive landscape of electronics, the demand for advanced printed circuit boards (PCBs) has never been higher. Our 12-layer PCB, constructed from Isola's 370HR material, is engineered to deliver superior thermal performance, reliability, and versatility.

Testing and Quality Assurance

A 100% electrical test is performed prior to shipment, ensuring that each PCB meets IPC-Class-2 standards. This rigorous testing process guarantees reliability and performance.

Impedance Matching

Impedance matching is critical for high-frequency applications. The following configurations are applied:

- Layer 1: 7mil single-ended, 100 ohm, referenced to Layer 2

- Layer 3: 9mil single-ended, 100 ohm, referenced to Layer 2

- Layer 4: 10mil single-ended, 100 ohm, referenced to Layer 5

- Layer 6: 7mil single-ended, 100 ohm, referenced to Layer 5

The 370HR Material

Isola's 370HR is engineered for multilayer PCB applications, boasting a glass transition temperature (Tg) of 180°C. This material excels in thermal performance, mechanical strength, and chemical resistance, surpassing traditional FR-4 materials.

Key Features

- High Thermal Performance: Tg of 180°C and Td of 340°C.

- Low Coefficient of Thermal Expansion (CTE): 13/14ppm/°C, ensuring reliability.

- RoHS Compliant: Free from harmful substances.

- CAF Resistant: Reduces the risk of conductive anodic filament issues.

- UV Blocking and AOI Fluorescence: Enhances compatibility with automated inspection systems.

Typical Applications

The versatility of this 12-layer PCB makes it suitable for a variety of applications, including:

- Computing, Storage, and Peripherals

- Networking and Communications

- Automotive and Transportation

- Consumer Electronics

- Aerospace and Defense

- Medical, Industrial, and Instrumentation

These industries benefit from the superior thermal stability and reliability of 370HR, making it ideal for high-performance devices.

Conclusion

This 12-layer PCB constructed with Isola's 370HR material represents the forefront of PCB technology. Its advanced construction, coupled with rigorous quality standards and high-performance features, makes it a vital component in modern electronics. With worldwide availability, this PCB is poised to meet the growing demands of various high-tech industries, ensuring reliability and performance in diverse applications.
