Pvc Coated 76.2*12.7mm Anti Climb Security Fencing Anti Corrosion
PVC coated high security anti-corrosion anti climb security fence
High security fencing , Prison Mesh Fencing or 358 Mesh Fencing as it is also known, is a highly robust steel Mesh Fencing system. It consists of horizontal and vertical mesh wires which are positioned close together to prevent people from fitting their fingers through the apertures, to ultimately climb the fencing.
"358" comes from its measurements 3"*0.5"*8 gauge which means approximately 76.2mm*12.7mm*4mm (mesh opening* wire diameter).358 Anti Climb Security Fence is one security fence that is extremely difficult to penetrate through, because the small mesh aperture is effectively finger proof, and extremely hard to attack by using conventional hand tools.
Customer Service
Fast and Accurate Quotes
Best Value, Quality Products
10 Year Warranty on most Products
Custom Design
As every project is different, we can manufacture to your specifications to ensure your unique design ideas
Quality Inspection
We have our own quality control department to provide special quality testing for our customers.
| Panel Description | |
| Mesh size | 3"(75mm)*0.5"(12.5mm) resistance welded well at each intersection |
| Wire diameter | 8 gauge(4mm) horizontal wire and vertical wire |
| Welded strength | Range 540-690N/m2 |
|
Surface treatment |
hot dipped galvanized steel wire, then PVC powder coating (Min. 100 micron), or PVC powder painting. It provides additional protection and increases the potential life span |
| Installation | Overlapped 75mm minimum at each post (shown as the below photo) for securing with slotted clamp bars and M8 diameter bolts |
| Post Description | |
| Material | high grade steel for maximum strength and rigidity |
| Post section | 60×60mm,80×60mm, 80×80mm or 120×60mm |
| Post plate thickness | 2.5mm or 3.0mm |
| inside and outside galvanized (Min. 275 g/m2), subsequently covered with a polymer powder (Min. 60 micron ) | |
| Colors | Green RAL 6005, or Black RAL 9005 |
| Post cap | 80×60mm and 120×60mm post with metal caps, and 80×80mm post with plastic cap |
| Metal clips and clamps are hot dip galvanized then powder coating in green or black color. | |
Fittings
