CNC Machining IGS ADC10 Aluminum Die Casting Mold
Product Description
Global Manufacturer of Custom Engineered Aluminum Die Casting Tooling;
Engineering With excellent dimensional accuracy;
Customer Oriented & Quality Adherence;
Competitively Priced Aluminum Die Casting Toolings;
Aluminum Molding Casting Tooling Standard:DME,HASCO,LKM,CUMSA,MISUMI,DAIDO.
|
Mold Material
|
SKD61, H13
|
|
Cavity
|
Single or multiple
|
|
Mold Life Time
|
50K times
|
|
Product Material
|
1) ADC10, ADC12, A360, A380, A413, A356, LM20, LM24
2) Zinc alloy 3#, 5#, 8# |
|
Surface Treatment
|
1) Polish, powder coating, lacquer coating, e-coating, sand blast, shot blast, anodine
2) Polish + zinc plating/chrome plating/pearl chrome plating/nickel plating/copper plating |
|
Size
|
1) According to customers' drawings
2) According to customers' samples |
|
Drawing Format
|
step, dwg, igs, pdf
|
|
Certificates
|
ISO 9001:2015 & IATF 16949
|
|
Payment Term
|
T/T, L/C, Trade Assurance
|
| Physical properties comparison of different die casting alloy | ||||
| Aluminum | Brass | Magnesium | Zinc | |
| Tensile strength,psi*1000 | 47 | 55 | 34 | 41 |
| Yield strength,psi*100(0.2 pct offset) | 23 | 30 | 23 | |
| Shear strength,psi*1000 | 28 | 37 | 20 | 31 |
| Fatigue strength,psi*1000 | 20 | 25 | 14 | 7 |
| Elongaton,pct in 2 in. | 3.5 | 15 | 3 | 10 |
| Hardness (Brinell) | 80 | 91 | 63 | 82 |
| Specific gravity | 2.71 | 8.3 | 1.8 | 6.6 |
| Weight,lb/cu.in. | 0.098 | 0.305 | 0.066 | 0.24 |
| Melting ponint (liquid),°F | 1100 | 1670 | 1105 | 728 |
Advantages of Die Casting:
1) High productivity, easy mechanization and automation, able to produce thin-walled castings with complex shapes.
The die-cast aluminum alloy has a minimum wall thickness of about 0.5 mm and a minimum cast hole diameter of 0.7 mm.
2) The casting has high dimensional accuracy and small surface roughness. The dimensional tolerance of die-casting parts can reach CT3~CT6, and the surface roughness is generally 0.8-3.2μm.
3) The castable parts in the die-casting parts not only save precious materials and machining man-hours, but also replace the assembly process of the parts, which can save the assembly process and simplify the manufacturing process.
