Strength Road Beds 45KN Biaxial Plastic Geogrid For Highways
Reinforce Various Highways Railways And Airports Road Beds Biaxial Plastic Geogrid
Biaxial Plastic Geogrid Introdution
Biaxial geogrid is made of Polypropylene resin as its raw material, ,it is produced through the process of extruding, punching, heating, longitudinal stretching and transverse stretching.
Biaxial Plastic Geogrid Technical Specifications
| project | TGSG15-15 | TGSG20-20 | TGSG25-25 | TGSG30-30 | TGSG40-40 | TGSG45-45 | TGSG50-50 |
| Tensile StrengthKN/m | 15 | 20 | 25 | 30 | 40 | 45 | 50 |
| Tensile StrengthKN/m | 15 | 20 | 25 | 30 | 40 | 45 | 50 |
| Tensile Strength @2% Strain KN/m | 5 | 7 | 9 | 10.5 | 14 | 16 | 17.5 |
| Tensile Strength @5% Strain KN/m | 7 | 14 | 17 | 21 | 28 | 32 | 35 |
| Roll width | 3.95 or 5.95 meters | ||||||
| Roll Length | 50 meters | ||||||
Biaxial Plastic Geogrid Features
1.High tension resistance, high plane torsion resistance modulus, good creep resistance and stable chemical nature.
2.High mechanic damage resistance and durability and large friction factor with sandy stone.
3. Improve the bearing capacity of the roadbed and extend the service life of the roadbed.
4. It can decrease 30%-40% of filling thickness for reaching same effect, save cost.
Biaxial Plastic Geogrid Usage
Reinforcement of road beds of various highways, railways and airports.
2. Reinforcement of permanent bearing road beds of large parking area and dock goods yard.
3. Slope protections and culvert reinforcement of railway and highway.
4. Secondary reinforcement of soil slope after unidirectional tension geotechnical grid reinforcement and further reinforcement of soil slope sp as to avoid soil erosion.
