Deep Groove Elevator Bearings P6 Precision V2 Vibration 2RZ 2RSR

Name: Deep Groove Elevator Bearings P6 Precision V2 Vibration 2RZ 2RSR
Brand: Anhui Thysenem Machinery Co., Ltd.

Price Negotiable

Price: Negotiated

MOQ: Negotiated

Delivery Time: Negotiated

Brand: DCM

Product Description

Deep Groove Ball Bearings 6000 Series OPEN N NR ZN Z RS RZ RSR 2Z 2RS P5 P6 ID 10- 300 mm Long life Low Noise

Features

Deep groove radial ball bearings are applicable for low to moderate thrust loads in both loading directions. Like the 6000 series, the 6200 series, the 6300 series is well suited for low to heavy radial loads and can be configured for various application speeds and running precision requirements.

Product Specification

Bearing No.	Boundary Dimensions(mm)				Basic Load Rating(kN)		Weight(kg)
Bearing No.	d	D	B	rs min	Cr	Cor	Weight(kg)
6000	10	26	8	0.3	4.55	1.97	0.018
6001	12	28	8	0.3	5	2.3	0.021
6002	15	32	9	0.3	5.5	2.8	0.03
6003	17	35	10	0.3	6	3.25	0.04
6004	20	42	12	0.6	9.38	5.03	0.068
6005	25	47	12	0.6	10.1	5.83	0.079
6006	30	55	13	1	13.2	8.3	0.113
6007	35	62	14	1	16.2	10.4	0.149
6008	40	68	15	1	17	11.7	0.185
6009	45	75	16	1	21	14.8	0.231
6010	50	80	16	1	22	16.3	0.25
6011	55	90	18	1.1	30.3	22	0.362
6012	60	95	18	1.1	31.7	24.2	0.385
6013	65	100	18	1.1	32	24.8	0.43
6014	70	110	20	1.1	38.6	30.4	0.569
6015	75	115	20	1.1	40.2	33.2	0.603
6016	80	125	22	1.1	47.5	39.8	0.821
6017	85	130	22	1.1	50.8	42.8	0.848
6018	90	140	24	1.5	58	49.9	1.12
6019	95	145	24	1.5	57.7	50	1.18
6020	100	150	24	1.5	60.5	54	1.25
6201	12	32	10	0.6	6	2.7	0.036
6202	15	35	11	0.6	7.8	3.75	0.045
6203	17	40	12	0.6	9.56	4.75	0.065
6204	20	47	14	1	12.7	6.55	0.103
6205	25	52	15	1	14	7.8	0.127
6206	30	62	16	1	19.5	11.2	0.203
6207	35	72	17	1.1	25.5	15.3	0.287
6208	40	80	18	1.1	30.7	19	0.367
6209	45	85	19	1.1	33.2	21.6	0.416
6210	50	90	20	1.1	35.1	23.2	0.462
6211	55	100	21	1.5	43.4	29.2	0.607
6212	60	110	22	1.5	47.5	32.5	0.783
6213	65	120	23	1.5	55.9	40.5	0.99
6214	70	125	24	1.5	60.5	45	1.1
6215	75	130	25	1.5	66.3	49	1.2
6216	80	140	26	2	70.2	55	1.4
6217	85	150	28	2	83.2	64	1.8
6218	90	160	30	2	95.6	73.5	2.15
6219	95	170	32	2.1	108	81.5	2.6
6220	100	180	34	2.1	122	92.7	3.2
6301	12	37	12	1	9.7	4.2	0.06
6302	15	42	13	1	11.4	5.4	0.082
6303	17	47	14	1	13.5	6.55	0.115
6304	20	52	15	1.1	15.9	7.8	0.141
6305	25	62	17	1.1	22.5	11.6	0.219
6306	30	72	19	1.1	28.1	16	0.35
6307	35	80	21	1.5	33.2	19	0.454
6308	40	90	23	1.5	31.4	22.4	0.639
6309	45	100	25	1.5	52.7	31.5	0.836
6310	50	110	27	2	61.8	38	1.05
6311	55	120	29	2	71.5	45	1.35
6312	60	130	31	2.1	81.9	52	1.7
6313	65	140	33	2.1	92.3	60	2.1
6314	70	150	35	2.1	104	68	2.5
6315	75	160	37	2.1	114	76.5	3
6316	80	170	39	2.1	124	86.5	3.6
6317	85	180	41	3	133	96.5	4.25
6318	90	190	43	3	143	108	4.9
6319	95	200	45	3	153	119	5.75
6320	100	215	47	3	174	140	7
