50ohm 380VAC 150-200A Emi Power Line Filter for shielded enclosure

Price Negotiable

Price: $500.00/pieces >=1 pieces

MOQ: Negotiable

Delivery Time: Negotiable

Brand: nenglv

Product Description

RATED VOLTAGE	380 VAC
RATED CURRENT	100 A
Voltage Drop	Less than 1V
Overload	140% of rated current for 15 minutes

Harmonic Distortion	Less than 2% @ full rated current
Leakage Current	≤0.2A@380/230VAC and 50Hz
Dielectric Withstanding Voltage	1000VDC (line to line) 1000VDC (line to case)
DC Insulation Resistance	As Per MIL-STD-202 Method 202

Terminal Strength	As Per MIL-STD-202 Method 211
Temperature Rise	As Per MIL-F-15733

Insertion Loss	≥100dB@14K-40GHz As Per MIL-STD-220A, Under Load Condition
Climatic Classification	25/070/21

DIMENSION

Our Company

We are a professional and famous EMI filter manufacturer.
Our technical team has more than 10 years’ experience in designing EMI filter. We know UL VDE CSA CE CQC etc safety standard very well.
Our technical service team learn many kinds of test standard such as industrial application (IEC61800-3 for frequency inverter drive EN12015 for elevator EN55011 for ISM device etc) and military application (GJB151A GJB152A etc).We can solve EMI problem quickly effectively and low-costly.
