HASL Lead Free Quick Turn Double Sided PCB
1. 2-20layer PCB.
2. Pad over via, Half PTH.
3. HASL-LF, ENIG,Hard gold plating.
4. PCB adhere to IPC Class 2 & 3 standard.
5. Orders from small to big batch.
6.All E-Test required.
| 1 | Layer | 2-20 layers |
| 2 | Material | FR4,CEM1,Aluminum,CEM3,PI, Rogers,TEFLON |
| 3 | PCB thickness | 0.2mm-6mm |
| 4 | Max board size | 1200*600mm |
| 5 | Min hole size | 0.1mm |
| 6 | Min line track | 0.075mm |
| 7 | Min line gap | 0.075mm |
| 8 | Surface finish | HASL-LF,ENIG, Hard Gold plating,Peelable |
| 9 | Copper weight | 18um-280um |
| 10 | Soldermask color | green/black/white/red/blue/yellow/orange |
| 11 | Outline Tolerance | ±0.13mm |
| 12 | Impedance control Tolerance | ±10% |
| 13 | Hole size tolerance | PTH:±0.075mm,NPTH:±0.05mm |
| 14 | Certification | UL,ISO9001,ISO14001,SGS,RoHS,ISO/TS16949 |
| 15 | Profile | Punch,Route,V Groove,Beveling |
| 16 | Production capacity | 60000 sqm/month |
FAQ
Q1:Are you a factory?
A: ABIS is a PCB/FPC/PCBA manufacturer/factory. We involved in PCB(A) Board more than 10 years.
Q2:Is my PCB file safe if I send it to you for manufacturing?
A: We will never manufacture PCB for someone else without your permission. NDA is available.
Q3:What is your testing policy and how you control the quality?
A: For sample, usually tested by flying probe; for PCB volume, usually tested by fixture, this will be more faster. Due to there's many steps to PCB production, we usually do inspection after every step.
Q4: What's your shipping way ?
A: 1. We have our own account by DHL, UPS, FEDEX, TNT.
Q5: What is your certificate?
A: ISO9001, ISO14001, UL, SGS,RoHS,TS16949.
Q6: What files should we offer?
A: If only need PCB, please provide Gerber File(DXF,RS274-X,ODB++) and manufacturing specifications; If need PCBA,Please provide Gerber File, Manufacturing specification, BOM list.
Q7: Can I get a sample?
A: Yes,
Q8: Does ABIS CIRCUITS bevel gold fingers?
A: Yes.
Q9: Why choose us?
A: With ABIS, customers significantly and effectively reduce their purchasing cost. Behind each service provided by ABIS, is hidden a cost saving for customers.
. We have two factories together, one is for prototype, quick turn, small volume making. The other is for mass production as well as HDI board
