Audio Product 1oz Copper 4 Layer PCB Board Assembly
4 Layer PCB Board Assembly Applied for Audio Product
Abis Circuits Co., Ltd is a professional PCB manufacturer which was established in Oct 2006 and focus on double side, Multilayer, and HDI PCB mass production.
We have two factories together, the factory in Shenzhen is specialized in small and middle volume orders and the factory in Huizhou is for big volume and HDI.
Factory: Operation plant space: (I) 10000 Square meters (II) 60000 Square meters
Employees: (I) 300 Man Powers (II) 900 Man Powers
Eng. Technical: (I) 20 QA QC Engineers (II) 60 QA, QC Engineers
Capacity
| Production Capacity | |
| PCB Max. size | DIP capacity |
| Min component size | 201 |
| Min. pin space of IC | 0.3mm |
| Min. space of BGA | 0.3mm |
| Max. precision of IC assembly | ±0.03mm |
| SMT capacity | ≥2 million points/day |
| DIP capacity | ≥100k parts/day |
Lead Time
| Category | Q/T Lead time | Standard Lead Time | Mass Production | |||
| 2 Layers | 24hrs | 3-4 working days | 8-15 working days | |||
| 4 Layers | 48hrs | 3-5 working days | 10-15 working days | |||
| 6 Layers | 72hrs | 3-6 working days | 10-15 working days | |||
| 8 Layers | 96hrs | 3-7 working days | 14-18 working days | |||
| 10 Layers | 120hrs | 3-8 working days | 14-18 working days | |||
| 12 Layers | 120hrs | 3-9 working days | 20-26 working days | |||
| 14 Layers | 144hrs | 3-10 working days | 20-26 working days | |||
| 16-20 Layers | Depends on the specific requirements | |||||
| 20+ Layers | Depends on the specific requirements | |||||
FAQ:
Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?
Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working file be approved, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
Quality Control
Multiple quality assuring procedures
* Visual Inspection
* Flying probe, fixture tool
* Impedance control
* Solder-ability detection
* Digital metallographic microscope
* AOI (Automated Optical Inspection
ABIS With Customer
ABIS cares every your order even 1 piece
