0.15mm Flexible Circuit Board
Price:
Negotiable
MOQ:
1pcs
Delivery Time:
0.5-4 week
Brand:
ABIS
Product Description
Flexible Circuit Board For Digital Imaging System
1. Digital imaging system.
2. PI substrate.
3. 0.15mm board thickness.
4. Immersion gold finish surface.
5. Test voltage 50-300V.
| 1 | Layer | Single layer |
| 2 | Material | PI |
| 3 | Board thickness | 0.15mm |
| 4 | Application | Digital imaging system |
| 5 | Surface finish | Immersion gold |
| 6 | Coverlay color | Yellow |
| 7 | Min hole ring | 7mil for 2OZ copper |
| 8 | Copper thick | 2OZ |
| 9 | Min line track | 0.3mm |
| 10 | Min sapcing | 0.3mm |
| 11 | Coverlay alignment tolerance | ±3mil |
| 14 | Certificate | RoHS compliant,UL,ISO9001/14001,TS16949,SGS |
FAQ
Q1:How about this board thickness?
A: 0.15mm.
Q2:Which copper weight you can do?
A: 11.7-70um.
Q3:Could you please share your client with us?
A: NDA signed with our clients, Therefore we do not reveal their name, If you want security, We can do same for you.
Q4: The copper foil is RA or ED type?
A: RA commonly.
Q5: FCCL type is with or without adhesive?
A: Without adhesive normally.
Q6: Do you make solder mask for flex circuit board?
A: Yes we do.
Certs and manufacturing equipment:
