Measure Instrument 4 Layer EMS Turnkey PCB Assembly
1. FR4 TG150 material.
2. Measure instrument application.
3. 2OZ outer copper weight.
4. Components size:min 0201.
5. 1.6mm standard board thickness.
| 1 | Layers | 4L |
| 2 | PCB material | FR4 TG150 |
| 3 | PCB thickness | 1.6mm |
| 4 | Used for | Measure Instrument |
| 5 | Surface finish | HASL lead free |
| 6 | Min via | 0.13mm |
| 7 | Mini chip part | 0201 package |
| 8 | Min line track | 0.18mm |
| 9 | Min line space | 0.18mm |
| 10 | Outer cu | 70um |
| 11 | Inner cu | 35um |
| 12 | Special process | Conformal coating |
| 13 | Solder resist | Green LPI |
| 14 | Certification | SGS,RoHS compliant,UL,ISO9001/14001,TS16949 |
| 15 | Min BGA space | 0.2mm |
FAQ
Q1:What is the minimum length of tape with components?
A: The Min package is 0201.
Q2:PCB assembly quality assurance?
A: Normally 1year.
Q3:What's your leadtime?
A: 3weeks commonly.
Q4: What is the required stock of components?
A: Usually for Capacitor and resistor,the MOQ is 4K,but for samples,we can order with 1PCS as well.
Q5: Are there any requirements for fiducial marks?
A: Yes,It will be required with fiducial mask,as all boards are automatic assembly.so we need to take a stencil to do that .
Q6: Share your export details?
A: HS code:85340090 for 1-4layer PCB, 85340010 for 4+layer PCB.
