6 Layers Flex Rigid PCB ENIG TG135 Flex PCB Prototyping For Consumer Electronics
Flex PCB Multi Circuit Boards Flex Pcb Board Flex Pcb Manufacturer Flex Pcb Prototype
Abis Circuits Co. Ltd is a great PCB manufacturer that was established in 2006 and is based in Shenzhen (China’s “Silicon Valley”).
Our company has about 1100 workers and two PCB workshops with about 50000 square meters.
Our products are mostly used in the field of Industrial Control, Telecommunication, Automotive products, Medical, Consumer, Security, and others.
What is Rigid-Flex PCB?
Rigid-flex board is a combination of two very important printed circuit boards: rigid printed circuit board (hard board) and flexible printed circuit board (FPC soft board), the English name is rigid-flex PCB. The circuits of the hard board part and the flex board part are interconnected by plated through holes. Rigid flex circuits offer higher component density and better quality control. The design is rigid, requires extra support, and corners and areas that require extra space. The hard board and the soft board are combined according to the relevant process requirements after the pressing process, and the circuit board with the characteristics of the FPC soft board and the hard board PCB is formed.
What is the PCB Fabrication of Rigid-Flex PCB?
Weight and Size
1. Small packaging size and a lightweight and compact circuit board solution due to the absence of connecting components. The lightweight design also helps to significantly reduce the overall weight of your device as a whole, making it best suited for smart and portable devices.
2. These flexible solutions are best suited in places where other PCBs may not be ideal, thus opening up the possibilities. They can also be folded and physically manipulated to fit into the nooks and crannies of your electronic gadget.
Functional Flexibility
1. It allows you to manufacture your board according to the electronic product or device you are aiming to make instead of having to manipulate the device based on the specifications of the PCB.
2. The polyimide material used to manufacture these flexible circuits makes them much better suited for high-temperature applications operating at values below -200 degrees or above 400 degrees Celsius.
3. They are also highly resistant to chemicals, radiation, and ultraviolet rays.
What capacity does ABIS have?
| Raw material | FR-4, High TG FR-4, PTFE, Aluminum Base, Cu base. Rogers, etc |
| Board Thickness | 0.20mm--8.00mm |
| Layer | 1 Layer-20 Layer |
| Insulation Layer Thickness | 0.075mm--5.00mm |
| Min.hole size | 0.1mm (drilling hole) |
| Max. Board size | 1200mm*600mm |
| Out Layer Copper Thickness | 18um--350um |
| Inner Layer Copper Thickness | 17um--175um |
| NPTH Hole Tolerance | +/- 0.075mm |
| PTH hole Tolerance | +/-0.05mm |
| Outline tolerance | +/-0.13mm |
| Surface finished | HASL, ENIG, Chem. Tin, Flash Gold, OSP, Gold finger |
| Solder Mask Type | LPI |
| Others | RFQ. |
What certificate does ABIS have?
We have ISO14001, ISO9001, UL, cUL, and TS16949. You can see more in our company profile.
What is your Lead Time?
| Category | Q/T Lead time | Standard Lead Time | Mass Production | |||
| 2 Layers | 24hrs | 3-4 working days | 8-15 working days | |||
| 4 Layers | 48hrs | 3-5 working days | 10-15 working days | |||
| 6 Layers | 72hrs | 3-6 working days | 10-15 working days | |||
| 8 Layers | 96hrs | 3-7 working days | 14-18 working days | |||
| 10 Layers | 120hrs | 3-8 working days | 14-18 working days | |||
| 12 Layers | 120hrs | 3-9 working days | 20-26 working days | |||
| 14 Layers | 144hrs | 3-10 working days | 20-26 working days | |||
| 16-20 Layers | Depends on the specific requirements | |||||
| 20+ Layers | Depends on the specific requirements | |||||
