Deep Groove Ball Bearing 6202 2RS,Single Row Deep Groove Ball Bearing 6202 2RS,China Ball Bearing 6202 2RS
6202 2RS made by Anhui Anheng Bearing Co.,Ltd with guranteed quality rate and very competitive price! From the quality rate ABEC1 Z1V1 to ABEC7 Z4V4,we choose high quality Gcr15 steel,G10 grade balls, our mass production for this item 99 percent can reach to Z3V3 easily.
Why Choose US:
1. We are manufacturer with more than 25 years industry experience,offer you the most competitive price and best quality.
2. Perfect group of technical engineers offer you the best support.
3. Well-trained group of International sales provide you the best service.
4. Smooth, silent and low vibration assure durability with long life.
5. Extensive range of bearing types, price, quality.
6. Our own brand “AHAHB”,OEM customization, customers' logo also available
7. Good ability of cost control brings you reasonable price, long-term partner of forwarder brings you low freight
8. Special discount and protection of sales area provide to our distributors
This Bearing Has Two Rubber Seals (2RS), Connected to the Inner Ring to Protect the Bearing from Dust or any Possible Contamination....
- This bearing has Rubber Seal on both sides, Connected to the Inner Ring to Protect the Bearing from Dust or any Possible Contamination. If your Application Requires a Ball Bearing with One Seal or Opened Without Seals, you can easily remove one or both Seals.
- Application: ATVs, Motorcycles, Snowmobiles, Snowblowers, Snow Thrower, Lawn Mowers, Go-KART, Automotive, Appliances, Sporting Machines, Agriculture Machines, Industrial Applications, Electric Motors, HVAC, Furnaces, Transmissions, Gearboxes, Elevators, Lifts and Hoists, Medical Devices...etc
- Specializing in the Exclusive Production of Bearings with High Performance, High Speed, Less Vibration, Low Noise, and Long Life.
| Bearing No. | Bore | O.D | Width | Load Rating(KN) | Ball Complement | Maxronout Speed | Weight(kg) | ||||||
| d | D | B | B | Dynamic | Static | No. | Size | Grease | Oil | ||||
| mm | in | mm | in | mm | in | Cr | Cor | mm | r/mm | r/mm | |||
| 625 | 5 | 0.1969 | 16 | 0.6299 | 5 | 0.1969 | 1.13 | 0.56 | 8 | 2.381 | 32000 | 40000 | 0.005 |
| 626 | 6 | 0.2362 | 19 | 0.7480 | 6 | 0.2362 | 2.01 | 1.05 | 6 | 3.500 | 28000 | 36000 | 0.008 |
| 627 | 7 | 0.2756 | 22 | 0.8661 | 7 | 0.2756 | 2.53 | 1.36 | 7 | 3.969 | 26000 | 34000 | 0.014 |
| 628 | 8 | 0.315 | 24 | 0.9449 | 8 | 0.3150 | 2.57 | 1.36 | 7 | 3.969 | 24000 | 32000 | 0.016 |
| 629 | 9 | 0.3543 | 26 | 1.0236 | 8 | 0.3150 | 3.52 | 1.95 | 7 | 4.763 | 22000 | 30000 | 0.019 |
| 6200 | 10 | 0.3937 | 30 | 1.1811 | 9 | 0.3543 | 5.10 | 2.39 | 8 | 4.763 | 25000 | 30000 | 0.032 |
| 6201 | 12 | 0.4724 | 32 | 1.2598 | 10 | 0.3937 | 6.10 | 2.75 | 7 | 5.953 | 22000 | 26000 | 0.037 |
| 6202 | 15 | 0.5906 | 35 | 1.3779 | 11 | 0.4331 | 7.75 | 3.60 | 8 | 5.953 | 19000 | 23000 | 0.045 |
| 6203 | 17 | 0.6693 | 40 | 1.5748 | 12 | 0.4724 | 9.60 | 4.60 | 8 | 6.747 | 18000 | 21000 | 0.065 |
| 6204 | 20 | 0.7874 | 47 | 1.8504 | 14 | 0.5512 | 12.80 | 6.65 | 8 | 7.938 | 16000 | 18000 | 0.110 |
| 6205 | 25 | 0.9843 | 52 | 2.0472 | 15 | 0.5906 | 14.00 | 7.85 | 9 | 7.938 | 13000 | 15000 | 0.130 |
| 6206 | 30 | 1.1811 | 62 | 2.4409 | 16 | 0.6299 | 19.50 | 11.30 | 9 | 9.525 | 11000 | 13000 | 0.200 |
| 6207 | 35 | 1.3779 | 72 | 2.8346 | 17 | 0.6693 | 25.70 | 15.30 | 9 | 11.112 | 9800 | 11000 | 0.290 |
| 6208 | 40 | 1.5748 | 80 | 3.1496 | 18 | 0.7087 | 29.10 | 17.80 | 9 | 12.000 | 8700 | 10000 | 0.370 |
| 6209 | 45 | 1.7716 | 85 | 3.3465 | 19 | 0.748 | 32.50 | 20.40 | 10 | 12.000 | 7800 | 9200 | 0.410 |
| 6210 | 50 | 1.965 | 90 | 3.5433 | 20 | 0.7841 | 35.00 | 23.20 | 10 | 12.700 | 7100 | 8300 | 0.460 |
