16kWh Rechargeable 51.2V 48V Pre-assembled 314ah Lithium Ion Battery Pack Seplos Smart BMS with Active Balancer
Price:
negotiation
MOQ:
1piece
Delivery Time:
3-5 working days
Product Description
16kWh Rechargeable Home Solar LiFePO4 Battery Pack
EU Stock with Free Shipping - Enjoy seamless ordering with guaranteed stock availability, free shipping, and fast delivery directly from our EU warehouse.
Key Differences Between V4 and V3 Models
- Added 250A circuit breaker for enhanced protection
- Touch screen display with Chinese and English language support
- Updated communication interface to RS485B-RS485A-CAN
- Slimmer design for easier parallel connection and space efficiency
- Angled control panel optimized for European standing ergonomics
- Convenient BMS weak current switch placement near upper display
- Available in three colors: black, white, and gray
Technical Specifications
| Battery Configuration | 1P16S |
| Rated Voltage | 51.2V |
| Operating Voltage Range | 43.2V~58.4V |
| Rated Capacity | 314Ah |
| Rated Energy | 16.0768kWh |
| Standard Charge/Discharge Current | 100A/200A @25±2℃ |
| Maximum Charge Current | 200A @25±2℃ |
| Maximum Discharge Current | 200A @25±2℃ |
| Operating Ambient Temperature | -10℃~35℃ (Storage within 1 month) 25±2℃ (Storage within 3 months) 65%±20% RH |
| Dimensions (L x W x H) | (898.5＋10) × 415 × 260 mm |
| Weight | 119.5Kg ± 3kg |
| Cycle Life | 8000 cycles @25℃ |
| IP Rating | IP20 |
Key Features
- Modular Design: Expand your battery capacity effortlessly by connecting up to 16 additional packs in parallel
- Customizable Options: Choose from popular cell suppliers like EVE and Envision to build battery packs up to 16kWh (cells supplied separately)
- Smart BMS: The included V3 SEPLOS BMS with Bluetooth seamlessly integrates with various inverters (Victron, Growatt, Sofar, Solis, etc.) via CAN & RS485
- Intuitive User Interface: Easily monitor battery status, charge/discharge rates, and system performance via the LCD color screen
- 250A DC Breaker: Provides reliable protection and safeguards your battery system from excessive currents and short circuits
- Active Balancing: Provides optimized cell performance and ensures balanced charging and discharging among individual cells
System Benefits
- Cost-Effective: Build your own battery pack at a fraction of the cost of pre-assembled options
- Tailored Performance: Customize your battery to meet your specific energy storage requirements
- Reliable Technology: Benefit from the proven performance and safety of LiFePO4 cells and V3 SEPLOS BMS
- Time Saving: DIY battery pack assembly requires only 2-3 hours
We also have separate kits and battery cells available. Please contact us if needed. Contact information is at the bottom of the page.
