JIS DC53 Cold Work Knife High Hardened Tool Steel

Price Negotiable

Price: usd 3-5/kg

MOQ: 1 pc

Delivery Time: 10-20 DAYS

Brand: TAKFORD

Product Description

JIS DC53 COLD WORK MOLD STEEl/HIGH QUALITY COLD WORK TOOL STEEL/HIGH HARDEN/KNIFE TOOL STEEL TOOL STEEL/DIE STEEL

DC53 COLD WORK MOLD STEEl

Equivalent grades	GB		DIN		AISI		DAIDO	BOHLER
	Cr8Mo1VSi		-		-		DC53	K340
Chemical Composition	C	Si	Mn	Cr	P	S	Mo	V
	0.90-1.10	0.80-1.20	0.40 MAX	7.50-8.50	0.03MAX	0.03MAX	1.80-2.20	0.20-0.50
Available size	Round Bar		Diameter				Length
			16-800mm				2000-6000mm
	Flat Bar		Thickness		Width			Length
			16-400mm		100-800mm			2000-6000mm
Surface condition	Black surface/ Grinded/ Machined
Annealed hardness	BELOW 225HB
Characteristics	Uniform distribution of fine carbides Excellent galling & wear resistance Exceptional toughness & fatigue resistance High temper resistance to support PVD & nitride surface treatments Machining & grinding characteristics superior to most other tool steels after heat treatment, the hardness is higher than SKD11; tenacity is twice of SKD11; high hardness and toughness
Applications	punches & dies, draw & forum dies, shear blades, shredder knives, thread & form rolls, cold heading dies, mill rolls & slitters
Heat Treatment	Austenitize		Double High Temperature Draw
	1030℃		520℃		HRC 62/64
			540℃		HRC 60/62
			550℃		HRC 58/60

Main Application

Line cutting processing of fine blanking die stamping and all kinds of purpose.Hard processing material plastic deformation with tools. Cold forging, deep drawing and thread rolling ide. High speed blanking punch, stainless steel plate punch.

Characteristics

It is a kind of high toughness, high abrasion resistance steel, high hardenability and wear resistance,machinability, be good abrasive.
