4ep+2e Series Poe Switch OEM ODM 100m 4 10 / 100Mbps Poe Ports
4EP+2E Series POE Switch
Overview
HK-4EP+2E is a 100M POE Switch with 4 10/100Mbps POE ports, with VLAN DIP it can easily have access to VLAN function. There are 2 10/100Mbps uplink port. Longest POE distance can reach 250M. It is designed for school, family, SEMs, small range surveillance and other network connections. All ports support wire speed forwarding and the rate is up to 100Mbps. Each port support 4KV port lightning protection to ensure stable operation.
Specification
| project | parameter |
| port |
4 10/100base-t Poe ports Two 10/100base-t uplink ports |
| Switching performance |
Backplane bandwidth: 1.6g MAC address table: 2K Support store and forward |
| Standard protocol |
IEEE802. 3, IEEE802. 3i 10Base-T, IEEE802. 3u 100Base-T, IEEE802. 3x Flow Control, IEEE802. 1q VLAN, IEEE802. 3af PoE, IEEE802. 3at PoE+ |
| Transmission medium and distance | Class V line: 100m in normal mode; Ultra long distance transmission mode: 250m |
| Poe |
Poe port: 4 DC52V, single port MAXIMUM POWER 30W Power supply line pair: 1/2 (+), 3/6 (-) |
| Power Supply |
Ac100~240v 50/60hz input Total power: 65W |
| indicator light |
P: Power indicator, s: ultra long distance transmission mode indicator, V: VLAN mode indicator; Poe indicator; Electric port link/act indicator |
| Use environment |
Operating temperature: -10~+55 ℃ Storage temperature: -40~+70 ℃ Operating humidity: 10~90% non condensing Storage humidity: 5~90% non condensing |
| physical characteristics |
Size (W x D x H): 200x120x44mm Weight: 0.85kg |
