30kw XDEM Concrete Delivery Pump 10 - 45 Cubic Meters Drag Pump

Price Negotiable

Price: USD325-3479

MOQ: 1set

Delivery Time: 15-25days

Brand: XDEM

Product Description

Specifications

Product Information	RM-15	RM-20	RM-25	RM-30	RM-40	RM-50
Maximum theoretical delivery volume	10-12 CBM	15-18CBM	20CBM	25CBM	35CBM	45CBM
Maximum outlet pressure	10-15Mpa	10-15Mpa	10-15Mpa	12-15Mpa	12-25Mpa	12-25Mpa
Maximum particle size of aggregate	≤20mm	≤20mm	≤10-30mm	≤30mm	≤30-40mm	≤40mm
Bore*diameter	Φ120*360mm	Φ120*500mm	Φ140*600mm	Φ140*1000mm	Φ160-1200mm	Φ200-1100mm
Diameter of delivery pipe	Φ63/80/ 100mm	Φ63/80/ 100mm	Φ80/ 100mm	Φ80/ 100mm	Φ100/ 125mm	Φ125mm
Motor power	15KW	18.5KW	30KW	37KW	45KW	55KW
Dimensions(mm)	1 550750 1200	19807501350	300011001300	368014501550	398016001580	420016001680
Host weight	580KG	800KG	1200KG	1850KG	2800KG	3200KG
Horizontal maximum theoretical conveying distance	60M	150M	180M	280M	350M	350M
Vertical maximum theoretical conveying distance	30M	30M	80M	100M	120M	120M

Concrete trailer pump is also called as concrete pump, which is a mechanical machine that is used to convey and pour concrete at construction sites. Generally speaking, concrete trailer pumps are divided into diesel and electric concrete pump trailer by its original motivation. Trailer pumps have the characteristics of long conveying distance, high productivity, and high transporting speed, which made it more and more welcomed among construction projects.
