YTO Brand 160hp Tractor ELG1604 Agriculture Tractor
Price:
USD42300
MOQ:
1 unit
Delivery Time:
45days
Brand:
YTO
Product Description
YTO 160HP ELG1604 Tractor with good quality and cheap price
agriculture tractor
farming tractor
ag tractor
tractor and farm equipment
tractor farm equipment
| Model | ELG1604 | ||||
| Driving Type | 4WD | ||||
| Dimension | Length | mm | 5430 | ||
| Width | mm | 2770(double rear wheel 3330) | |||
| Height | mm | 3310 | |||
| Min. Ground clearance | mm | 490 | |||
| Min. Operating weight(Cabin) | Kg | 6580(double rear wheel 7270) | |||
| Engine | Model | SC7H175G3(Shangchai) | |||
| Rated Power | Kw/hp | 110/150 | |||
| Total Power | Kw/hp | 136/170 | |||
| Rotary Speed | rpm | 2300 | |||
| Type | 6 cylinder, high pressure common rail, supercharged cooling | ||||
| Air filter | Desert air filter | ||||
| Fuel & water separator | Equipped | ||||
| Walking system | Gear | 18F/6R | |||
| Speed farward | km/h | 2.0-39.0 | |||
| Main clutch | 15in',Air assisted foot pedal | ||||
| Tire | F/R | 14.9-28/18.4-38 | |||
| Tread | Front | mm | 1770-2208 | ||
| Rear | mm | 1730~2228(Double rear wheel 2324) | |||
| Steering Type | Hydraulic | ||||
| Minimum turning radius | m | 7.0±0.3 | |||
| Brake Type | Wet type, disc type | ||||
| Cabin | Cabin and accessories | Streamline cabin with A/C, ventilation,luxury seat,backup camera, Mp3 player, toolsbox. | |||
| Working lamp | LED (Front 2 and rear 4) | ||||
| Fuel tank | Capacity | 275L | |||
| Hydraulic System | Suspension Gear | 3P | Ⅲ | ||
| Lifting Power | Hinge Joint | KN | ≥58 | ||
| 610mm | ≥37 | ||||
| Hydraulic output | Unit | 3 | |||
| PTO | Type | Electro hydraulic independent control | |||
| Rotary Speed | rpm | 540/1000 | |||
| Power | Kw/hp | 100/136 | |||
| Tillage depth control mode | Draft and position control with quick up-down | ||||
