Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift

Name: Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift
Brand: Nanyang Xinda Electro-Mechanical Co., Ltd.

Price Negotiable

Price: USD16900/set

MOQ: 1 set

Delivery Time: 30 working days

Brand: XDEM

Product Description

lithium battery forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t hydraulic electric forklift

Model: CPD

Loading capacity: 1500kg / 2000kg / 3000kg / 4000kg

Load center: 500mm

Lifting height: 3000-6000mm

1) China top brand lithium battery, 80V/150Ah, 80V/202Ah, 80V/280Ah, 80V/404Ah, water automatic filling system is poptional.

2) Mast optional: 3/4m duplex mast, 3.6/4/4.5/5/5.5/6m triplex mast, 3/3.3/3.5/4/m duplex full free mast.

3) Transmission: Automatic/manual;

4) Tire: pneumatic/Solid/non-mark solid;

5) Forks: 1070/1220/1370/1520/1670/1820/1970mm;

6) Attachments: Side shifter, fork positoner, fork sleeve, paper roller clamp, bale clamp, drum clamp, load extender, rotator,

fork clamps, push/pull, etc..

7) Additional: Cabin, heating, fan, air conditioner, high exhaust, paper fold, USB, camera & image, suspension seat, etc.

Wide view

The compact structure of standard wide view frame and hose pulley block makes the operator a better view.

Reinforced components

The maintenance-free wet disc brake system provides excellent brake performance. The compact structure, small deflection, and

dust-proof and water-proof design of the casting steering axle endow the forklift with long service life and working reliability.

Advanced AC motor

Compared with DC motor, the maximum speed of AC motor is higher, which is more compact yet more powerful. With faster start-up

response, the forklift can run at full speed over short dis-tances. No need to replace the carbon brush or diverter, thus saving

maintenance cost.

High quality lead-acid battery

Cost-effective lead-acid battery is adopted, which has the characteristics of high-rate discharge performance, no ignitability,

large temperature window, zero pollution, high recycling rate, and long service life.

Low voltage DC charger

Corresponding low voltage DC charger is provided based on the power of lead-acid battery. Equipped with China national standard

charging gun,butt converter of different specifications are optionally provided to meet various charging specifications.

Characteristics
Manufacturer			XDEM
Model			CPD20	CPD25
Rated capacity	Q	kg	2000	1500
Load center distance	C	mm	500	500
Power type			Lithium Battery	Lithium Battery
Driving type			Seated	Seated
Wheel base	L1	mm	1500	1500
Tyres
Tyre type			Pneumatic	Pneumatic
Wheel number(front/rear)			2X/2	2X/2
Front tread	W3	mm	970	970
Rear tread	W2	mm	950	950
Tyre(front)			7.00-12-12PR	7.00-12-12PR
Tyre(rear)			18X7-8PR	18X7-8PR
Size
Front overhang	L2	mm	468	468
Mast tilting angle,front/rear	α/β	°	6/12	6/12
Height with mast retraction	H1	mm	1995	1995
Free lifting height	H3	mm	150	150
Max. lifting height	H	mm	3000	3000
Max. height after lifting	H2	mm	4045	4045
Overall guard height	H4	mm	2098	2098
Fork size: length x width x thickness	LxWxT	mm	1070x100x40	1070x120x40
Overall length(fork excluded)	L'	mm	2353	2353
Overall width	W1	mm	1170	1170
Turning radius	r	mm	2172	2172
Ground clearance of mast	H5	mm	110	110
Ground clearance of wheel base center(loaded)	H6	mm	105	105
Right angle stacking aisle width (pallet 1000x1000mm,clearance 200mm)	Ast	mm	4040	4040
Right angle stacking aisle width (pallet 1200x1200mm,clearance 200mm)	Ast	mm	4240	4240
Lateral fork adjustment Max./Min.	W5	mm	1038/200	1038/240
Performance
Travelling speed (loaded/unloaded)		km/h	12/14	12/14
Lifting speed (loaded/unloaded)		mm/s	320/450	320/450
Lowering speed		mm/s	<600	<600
Gradeability (loaded)		%	12	12
Weight
Total weight		Kg	4214	4270
Battery
Battery voltage /capacity		V/Ah	80/202	80/230
Lithium Battery weight		Kg	715	750
Motor and controller
Driving motor power-60 minutes		Kw	11	11
Lifting motor power(S3 15%)		Kw	12	12
Driving motor control mode			AC	AC
Lifting motor control mode			AC	AC
Service brake/parking brake			Hydraulic /Mechanical	Hydraulic /Mechanical
Hydraulic system working pressure		Mpa	17.5	17.5
Note: (1)Detailed information about battery,please contact our salesmen or engineer.
