15-50t/H Mini Mobile Jaw Crusher Station For Small Crushing Production Line
Mini Mobile Jaw Crusher Instruction
Mini Mobile Jaw Crusher is major machine for earth moving field. It represents a real revolution for small yards with lack of space. The smallest dimensions for the highest performances. Mini Mobile Jaw Crusher is designed for inert grinding, it is for the use in small yards with lack of space.
Mini Mobile Jaw Crusher Features
This crusher only require on operator. Equipped by tracks and radio remote control, it directly re-utilizes the ground material. In this way, it avoids transport costs.
It can reduce expenses because of the low operating costs, and totally avoiding the landfill.
Mini Mobile Jaw Crusher Technical Details:
| Model | HYPE250 | HYPE400 | |
| Feeding Equipment | Stock Bin Volume (m3) | 1 | 1 |
| Feeding Conveyor | B400x1500mm | B500x1800mm | |
| Max. Feeding Size (mm) | 220 | 380 | |
| Power (kw) | 1.1 | 2.2 | |
| Capacity (t/h) | 15-25 | 30-50 | |
| Crushing Equipment | Model | PE250x400 | PE400x600 |
| Capacity (t/h) | 15-25 | 30-50 | |
| Power (kw) | 15 | 30 | |
| Discharging Equipment | Discharging Conveyor | B400x4000mm | B500x5000mm |
| Walking System | Track Chassis | B250x2000 (Rubber) | B300x2500 (Steel) |
| Overall Unit | Equipment weight (t) | 5.3 | 9.5 |
| Overall Dimensions (LxWxH) | 5000x1500x2200mm | 6000x1500x2200mm |
