China SM G657A1 900um Tight Buffer LSZH 1M SC APC Fiber Optic Pigtail for sale

SM G657A1 900um Tight Buffer LSZH 1M SC APC Fiber Optic Pigtail

Price Negotiable

Price: Negotiable

MOQ: 10pcs

Delivery Time: Negotiable

Brand: KNOFC or OEM

Product Description

SC APC Pigtail Optical SM G657A1 900um Tight Buffer LSZH 1M

Description:

The optical Fiber Connectors (Commonly we call Patch Cords) is a length of optical cable with connectors fixed on one ends to realize the optical path active connection. Pigtail is a length fiber cable with only one connector fixed on one end. According to the transmission medium, it divides Single Mode and Multi Mode; according to the connector structure type, it divides FC, SC, ST, MU, D4, E2000,LC etc.; according to the polished ceramic end-face, it divides PC, UPC and APC.

Features:

Good durability.
Good exchangeability.
High temperature stability.
Low insertion loss and back reflection loss.
Superior Quality Standard PC/UPC/APC Polishin.

Application:

FTTH, LAN, Test equipment, Military industry.
Outside plant.
Premise networks.
Aerial distribution.
Measuring equipments.
Fiber optic communication system.
Optical active component and equipment.

Specification:

Parameter	Unit	Mode Type	PC	UPC	APC
Insertion Loss	dB	SM	≤0.3	≤0.3	≤0.3
Insertion Loss	dB	MM	≤0.3	≤0.3	-----
Return Loss	dB	SM	≥50	≥50	≥60
Return Loss	dB	MM	≥35	≥35	-----

Fiber cable	Material	PVC, LSZH
Fiber cable	Diameter	0.9mm, 2.0mm, 3.0mm
Connector type		SC, LC. ST. FC
Repeatability	dB	Additional loss<0.1db,return loss< 5 dB
Interchangeability	dB	Additional loss<0.1db,return loss< 5 dB
Connection times	times	>1000
Operating Temperature	℃	-20℃- +70℃
Storage Temperature	℃	-20℃- +70℃
