Ship Plate ASTM A36 Aisi 1020 Q235 Cold Roll Steel Coil
Aisi 1020 Cold Rolled Carbon Steel Coils Price
| AISI 1020 steel is additionally referred to as C1020 steel in cold worked (cold rolled and cold drawn) condition. 1020 steel is one among the foremost commonly used plain carbon steels, has good machinability and weldability. SAE AISI 1020 low-carbon steel are often hot rolled or cold drawn, but it's usually in turned and polished or cold drawn conditions. thanks to its low carbon content, it's immune to induction hardening or flame hardening. Aisi 1020 Cold Rolled Carbon Steel Application ASTM AISI SAE 1020 steel has many semi-finished products, like square steel bars, flat steel bars, round steel bars, steel plates, which may be wont to make truck, automotive and agricultural equipment parts like axles, mechanical parts, cold head bolts, motor shafts, pump shafts, ratchet, light gear, gear drives, worm gear, spindle, seat bracket, crane-cable drum, motor-brake wheel, etc. and typically also made into steel channels, steel angles, I-beams and H-beams. AISI 1020 Steel Datasheet & Specification The data sheet below lists SAE AISI 1020 steel properties and therefore the chemical composition. |
Aisi 1020 steel properties
|
The following data shows that AISI SAE 1020 steel mechanical properties include yield strength, tensile strength, elongation, section reduction, and hardness in various conditions. |
| AISI 1020 steel mechanical properties in heat-treated or cold-worked conditions | |||||||
| Steel (UNS) | Tensile strength, MPa (ksi) | Yield strength, MPa (ksi) | Elongation in 50 mm, % | Reduction in area, % | Hardness (HB) | Processing, condition or treatment | Sample Size, mm (in.) |
| 1020 (G10200) | 380 (55) | 205 (30) | 25 | 50 | 111 | Hot rolled | 19-31.8 mm (0.75-1.25 in.) |
| 420 (61) | 350 (51) | 15 | 41 | 121 | Cold drawn | ||
| ASTM AISI SAE 1020 steel mechanical properties in the hot-rolled, normalized, and annealed condition | |||||||||||
| UNS | Grade | Tensile strength, MPa (ksi) | Yield strength, MPa (ksi) | Elongation in 50 mm, % | Reduction in area, % | Hardness (HB) | Processing, condition or treatment | Austenitizing temperature, °C (°F) | Quenching agent | Izod impact strength, J, (ft·lbf) | Sample Size |
| G10200 | 1020 | 448 (65) | 331 (48) | 36 | 59 | 143 | As-rolled | – | Oil | 87 (64) | 12.8 mm (0.505 in.) machined from 25.4 mm (1 in.) rounds. |
| 441 (64) | 346.5 (50.3) | 35.8 | 68 | 131 | Normalized | 870 (1600) | Oil | 118 (87) | |||
| 394.7 (57.3) | 295 (43) | 36.5 | 66 | 111 | Annealed | 870 (1600) | Oil | 123 (91) | |||
| Cyclic fatigue properties | |||||||
| UNS | Grade | Cyclic strength coefficient, MPa (ksi) | Fatigue strength coefficient, MPa (ksi) | Fatigue strength exponent | Fatigue ductility coefficient | Fatigue ductility exponent | Hardness (HB) |
| G10200 | SAE 1020 steel | 1205 (175) | 850 (123) | -0.12 | 0.44 | -0.51 | 108 |
|
Q: Are you trading company or manufacturer ? A: We are professional manufacturer for steel pipe, and our company also is a very professional a trade company for steel products.we can also provide a wide range of steel products.
Q: Do you provide samples ? is it free or extra ?
Q: Do you accept the third party inspection?
Q: How could you guarantee your products? A: Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q: How do we trust your company? A: We specialise in steel business for years, headquarter locates in Jinan, Shandong province, you are welcome to investigate in any ways, by all means, you could place an order in Alibaba with trade assurance which could secure your payment. |
