Ams5659 15 5ph H1025 Cold Drawn Stainless Steel Bar Stock
Ams5659 15 5ph H1025 Cold Drawn Stainless Steel Bar Stock Suppliers Price For Sale, Sizes And Weight
| 15-5 Cold Drawn Stainless Steel Bar is a martensitic, precipitation-hardening material with chromium, nickel and copper. It is often a first choice in the aerospace industry for fasteners and structural components. Its unique structure provides increased toughness and better corrosion resistance than its predecessor, 17-4 PH. Both inclusion control and a minimized amount of delta ferrite as compared to 17-4 stainless steel contribute to the greater toughness of 15-5. The alloy is further strengthened by a low temperature heat treatment which precipitates a copper containing phase in the alloy. 15-5 PH is able to meet the stringent mechanical properties required in the aerospace and nuclear industries. |
15 5ph Cold Drawn Stainless Steel Bar Standard Inventory Specifications
# ams 5659
# astm a 564
# 15 5 ph ams 5659
# uns s15500
# sae ams 5659
# ams 5659 spec
15 5ph Cold Drawn Stainless Steel Bar Chemical Composition
| Element | Percent by Weight | |
| C | Carbon | 0.07 maximum |
| Cr | Chromium |
14 - 15.5 |
|
Cu |
Copper |
2.5 - 4.5 |
| Fe | Iron | Balance |
| Si | Silicon |
1.00 maximum |
| S | Sulfur |
0.03 maximum |
| Ni | Nickel |
3.5 - 5.5 |
| Mn | Manganese |
1.0 maximum |
| P | Phosphorus |
0.04 maximum |
| Nb | Niobium plus Tantalum |
0.15 - 0.45 |
15 5ph Cold Drawn Stainless Steel Bar Physical Properties
|
Condition |
A |
H900 |
H 1075 |
H1150 |
|
Density g/cm (3) |
7.75 |
7.81 |
7.83 |
7.86 |
|
Density lb/in (3) |
0.280 |
0.282 |
0.283 |
0.284 |
|
Thermal Conductivity 70-212° |
10.6 |
10.3 |
|
|
|
Thermal Conductivity 70-932° |
13.1 |
13.1 |
|
|
|
Electrical Resistivity |
98 |
77 |
80 |
86 |
15 5ph Cold Drawn Stainless Steel Bar Mechanical Properties
|
Condition |
Ultimate Tensile Strenght |
Yield Strength |
Elongation |
Reduction of Area |
Hardness Brinell |
Hardness Rockwell |
| H900 | 190,000 | 170,000 | 6 | 15 | 388 | C40 |
| H1025 |
155,000 |
125,000 | 8 | 27 | 331 | C35 |
| H1075 | 145,000 | 125,000 | 9 | 28 | 311 | C32 |
|
H1150 |
135,000 | 105,000 | 11 | 30 | 277 | C28 |
|
H1150-M |
115,000 | 75,000 | 14 | 35 | 255 |
|
Q: How can you assure your quality? A:1.We can provide you certificate of quality accordingly. 2.We are willing to accept the third party inspection, such as SGS,BV,CE and so on.
Q: Can you accept customization? A:Yes. If you have special requirements on products or packages, we can do customization for you.
Q: Can you accept trail orders? A:Gemerally our MOQ is 1 ton. But if you want to place a trail order as the beginning of our cooperation, we can accept smaller quantity at frist. Surely we will have further and longer partnership after the beginning.
Q: Can you provide samples for checking before order? A: Free samples can be provided as you required. You need only to bear the freight cost. |
