Small 26650 2500mAh Cylindrical Lifepo4 Cells Discharge Rate A123
Small 26650 2500mAh Cylindrical Lifepo4 Cells Discharge Rate A123
Discharge Rate A123 26650 LiFePO4 Cylindrical Battery Cell 2500mAh for 12V Automotive Starting Battery
Specification
| No. | Items | Specifications |
| 1 | Nominal Voltage | 3.2V |
| 2 | Nominal Capacity | 2.5Ah |
| 3 | Standard Charge Current | 0.2C |
| 4 | Max. Charge Current | 1C |
| 5 | Continuous Discharge current | 30C |
| 6 | Peak Discharge Current | 60C |
| 7 | Charge Cut-off Voltage | 3.9V |
| 8 | Discharge Cut-off Voltage | 2.0V |
| 9 | Inner Resistance (Impedance) |
(1kHz AC)≤ 6mΩ typical |
| 10 | Weight | 72g |
| 11 | Dimensions | Length: 65mm Width: 26.25 mm |
| 12 | Operating Temperature | Charging: 0°C ~ 45°C Discharging: -20°C ~ 60°C (The cell surface temperature cannot exceed 70°C) |
| 13 | Storage Temperature/Humidity | Temperature: -10°C ~ +35°C Humidity:65%±20%RH (optimal store temperature of 23 ± 5°C for long term storage) |
| 14 | Cycle Life | ≥2000 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard) |
Features:
* High capacity and stable discharge voltage
* Longer working time with high performance
* Light weight with small size
* Outstanding discharge properties and small internal resistance
* No memory effect, good discharge ability and high load and resist high temperature
* Pollution free for environmental protection
* 100% Authentic original li-iron rechargeable battery
* Bulid in anti-explosion protection and circuit protection
Applications:
* Passenger and commercial plug-in hybrid electric vehicles (PHEVs)
* Passenger and commercial battery electric vehicles (BEVs)
* Mild and micro hybrid vehicles
* Long-Duration (LD) grid energy storage systems
* Electric vehicles and charging stations, tourist coaches, yachts, wind and solar energy storage power, traffic signals
* Solar hybrid street lighting, UPS power supply, home storage
* Coal, disaster relief emergency, weather radar, electricity, smart grid, communication base stations
* Hospitals, finance, telecommunications , system critical backup power systems
1,Q: What's the main product in GEB?
A: Rechargeable battery. Li-ion, Lipo battery and power battery pack.
2,Q: What is overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode. Observe changes in battery appearance.
3,Q: What is over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in battery appearance
4. Q: Can I have a sample order?
A: Yes, we accept sample order to test and check quality. Batteries can be made as require.
5. Q: Do you have MOQ limit?
A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.
6. Q: How about the lead time?
A: Samples will takes 5-7 business days. Mass production will takes 25-30 days. It depends on quantity.
7. Q: How about shipping and delivery time?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP service, delivery time is 11-15 business days. Airline and sea shipping also available.
8. Q: What about after-sale service?
A: We will offer you 1 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.
