24 48 96 Core Overhead Self Supporting Figure 8 Fiber Optic Cable Single Mode G652d Armored GYTC8S GYTC8A
Overhead Self Supporting Figure 8 Fiber Optic Cable Gytc8a Gytc8s
Cable Specification
Item Name:GYTC8S cable
Optical Mode:Singlemode/Multimode
Fiber Diameters:G652, G655, 50/125μm, 62.5/125μm
Total Fiber Count:2-144
Bend Radius(Static/Dynamic):10D/20D
Working Life:More than 25 years
Application
Aerial self-supporting,Local network,Local network,Long distance network communication
| Fiber count | 12core |
| Fiber Type: | G652D/G657A1/G657A2 |
| Crush Resistance Long term: | 300 (N/100MM) |
| Crush Resistance Short term: | 1000(N/100MM) |
| Overall Diameter | 11.4mm~13.10mm |
| Sheath | PE |
| Strand Steel wire | 7*1.0mm |
| Sample Status | In stock |
Structure
Figure 8 non armoured fiber cable consists of :
1.Stranded loose tube
2.Steel wire strength member
3.Core filler compound
4.Fillers
5.Phosphating or Galvanized steel wire
6.PE sheath
Standards and Certificate
Fiber optical cable complies with Standard YD/T 769-2003,IEC60794-1
Certificate:CE ROHS ISO9001
Packaing detail
1km/ 2km/3km/4km/5km per wooden drum
Shipping
By sea/by air or express delivery,it depends on the order quantity
Lead time:
| Quantity(km) | 1-300 | Above 300 |
| Earliest time(day) | 5-7 | Negotiable |
