GYFTY Non Metallic Strength Member Outdoor Fiber Optic Cable Non Armored Anti EMI Design
GYFTY Non Metallic Strength Member Non Armored Outdoor Fiber Optic Cable
Product Description
GYFTY is a non armored outdoor fiber optic cable with a non metallic FRP central strength member. Optical fibers are placed in hydrolysis resistant loose tubes filled with water blocking compound. The cable core is stranded into a compact structure and protected by a PE outer jacket, ensuring stable performance for aerial and duct installation.
Key Features
-
Non metallic FRP strength member anti EMI
-
Good mechanical and temperature performance
-
Hydrolysis resistant loose tube design
-
Water blocking compound for reliable protection
-
Good flexibility and crush resistance
Product Standard / PRODUCT
·GYFTY cable complies with Standard YD/T 901-2009 as well as IEC 60794-1.
Optical Characteristics / PRODUCT
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation (+20℃) |
@850nm | ≤3.0dB/km | ≤3.0dB/km | ||
| @1300nm | ≤1.0dB/km | ≤1.0dB/km | |||
| @1310nm | ≤0.36dB/km | ≤0.36dB/km | |||
| @1550nm | ≤0.22dB/km | ≤0.23dB/km | |||
| Bandwidth (Class A) | @850 | ≥500MHZ·km | ≥200MHZ·km | ||
| @1300 | ≥1000MHZ·km | ≥600MHZ·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm | |||
Technical Parameters / PRODUCT
| Cable Type | Fiber Count | Loose tube count | Filler count | Cable Diameter Mm |
Cable Weight Kg/km |
Tensile Strength Long/short term N |
Crush Resistance Long/short term N/100mm |
Bending Radius Static/dynamic mm |
| GYFTY-2~6 | 2~6 | 1 | 4 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-8~12 | 8~12 | 2 | 3 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-14~18 | 14~18 | 3 | 2 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-20~24 | 20~24 | 4 | 1 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-26~30 | 26~30 | 5 | 0 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-32~36 | 32~36 | 5 | 0 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-38~48 | 38~48 | 5 | 0 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-50~60 | 50~60 | 5 | 0 | 9.0 | 88 | 800/1500 | 500/1000 | 15D/30D |
| GYFTY-62~72 | 62~72 | 6 | 0 | 9.5 | 100 | 1000/2000 | 500/1000 | 15D/30D |
| GYFTY-74~84 | 74~84 | 7 | 1 | 10.5 | 120 | 1000/2000 | 500/1000 | 15D/30D |
| GYFTY-86~96 | 86~96 | 8 | 0 | 10.5 | 120 | 1500/2500 | 500/1000 | 15D/30D |
| GYFTY-98~108 | 98~108 | 9 | 1 | 11.5 | 150 | 1500/2500 | 500/1000 | 15D/30D |
| GYFTY-110~120 | 110~120 | 10 | 0 | 12.0 | 150 | 1500/2500 | 500/1000 | 15D/30D |
| GYFTY-122~144 | 122~144 | 12 | 0 | 13.0 | 150 | 1500/2500 | 500/1000 | 15D/30D |
| GYFTY-146~216 | 146~216 | 18 | 0 | 13.0 | 150 | 1000/2000 | 500/1000 | 15D/30D |
storage/Operating Temperature : -40℃ to + 70℃
FAQ
1 Are you a manufacturer
Yes we are a direct factory in Guangzhou China
2 What is the minimum order quantity
MOQ is 1 km Trial orders are supported
3 Can I get a sample
Free samples are available Freight collected
4 What payment methods do you accept
T T L C Western Union and PayPal
5 What is the delivery time
Usually 3 to 7 working days depending on quantity
6 Do you support customization
Yes OEM ODM service and logo printing are available
