FTTH OEM 62 5 125um Fiber Optic Pigtail SC APC Connector for Telecom Networks
FTTH OEM 62 5 125um Fiber Optic Pigtail SC APC Connector for Telecom Networks
Fiber Optic Pigtail Features
-
Compatible with SC, LC, FC, MU, ST, MT-RJ, and E2000 connectors
-
PC, UPC, APC, and SPC polishing options available
-
Optional cable diameters: 0.9 mm, 2.0 mm, 3.0 mm
-
Single mode (9/125) and multimode (50/125, 62.5/125) fiber options
-
Supports simplex and duplex configurations
-
Low insertion loss and high return loss
-
Good interchangeability and long service life
Fiber Optic Pigtail Applications
-
FTTH and FTTx access networks
-
Telecom and data center fiber termination
-
Optical distribution frames (ODF) and patch panels
-
LAN and WAN network installations
-
Fiber splicing and network maintenance
| Item | SM(Single Mode) | MM(Multimode) | |||
| Fiber Cable Type | G652D/G655/G657A1/G657A2 | OM1 | OM2/OM3/OM4 | ||
| Fiber Diameter (um) | 9/125 | 62.5/125 | 50/125 | ||
| Cable OD (mm) | 0.9/1.6/1.8/2.0/2.4/3.0 | ||||
| Endface Type | PC | UPC | APC | UPC | UPC |
| Typical Insertion Loss (dB) | <0.2 | <0.15 | <0.2 | <0.1 | <0.1 |
| Return Loss (dB) | >45 | >50 | >60 | / | |
| Insert-pull Test (dB) | <0.2 | <0.3 | <0.15 | ||
| Interchangeability (dB) | <0.1 | <0.15 | <0.1 | ||
| Anti-tensile Force (N) | >70 | ||||
| Temperature Range (℃) | -40~+80 | ||||
|
Item
|
SM(Single Mode)
|
MM(Multimode)
|
|||
|
Fiber Cable Type
|
G652D/G655/G657A1/G657A2
|
OM1
|
OM2/OM3/OM4
|
||
|
Fiber Diameter (um)
|
9/125
|
62.5/125
|
50/125
|
||
|
Cable OD (mm)
|
0.9/1.6/1.8/2.0/2.4/3.0
|
||||
|
Endface Type
|
PC
|
UPC
|
APC
|
UPC
|
UPC
|
|
Typical Insertion Loss (dB)
|
<0.2
|
<0.15
|
<0.2
|
<0.1
|
<0.1
|
|
Return Loss (dB)
|
>45
|
>50
|
>60
|
/
|
|
|
Insert-pull Test (dB)
|
<0.2
|
<0.3
|
<0.15
|
||
|
Interchangeability (dB)
|
<0.1
|
<0.15
|
<0.1
|
||
|
Anti-tensile Force (N)
|
>70
|
||||
|
Temperature Range (℃)
|
-40~+80
|
||||
FAQ
1. Are you a real manufacturer?
Yes. We are a professional factory located in Guangzhou, China. Factory visits are welcome.
2. What is your minimum order quantity (MOQ)?
The standard MOQ is 1 km. Trial orders are available to support new projects.
3. Can I get a sample?
Yes. Free samples are available. Customers only need to cover the express shipping cost.
4. What payment methods do you accept?
We accept T/T, L/C, Western Union, and PayPal.
5. What is the delivery time?
Normally 3–7 working days, depending on order quantity and product specifications.
6. Do you support customized products and logo?
Yes. We provide OEM & ODM services, including customized specifications and branding.
