Figure 8 Overhead Fiber Optic Cable Gytc8s Self Support Loose Tube Stranded 16 24 48 Core

Name: Figure 8 Overhead Fiber Optic Cable Gytc8s Self Support Loose Tube Stranded 16 24 48 Core
Brand: Guangzhou Jiqian Fiber Optic Cable Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: 1KM

Delivery Time: 3-5 days, it depends on your quantity

Brand: Jiqian

Product Description

Gytc8s Self Support Loose Tube Stranded 16 24 48 Core Figure 8 Overhead Fiber Optical Cable
Characteristics
· Good mechanical and temperature performance

· High strength loose tube that is hydrolysis resistant

· Special tube filling compound ensure a critical protection of fiber

· Crush resistance and flexibility
· Storage/Operating Temperature: -40°C to + 70°C
Features:
Figure 8 non-armored fiber cable consists of :
1.Stranded loose tube
2.FRP strength member
3.Core filler compound
4.Fillers
5.Phosphating or Galvanized steel wire
6.PE sheath
Optical Characteristics:

			G.652D
			50/125μm
			62.5/125μm

			Attenuation (+20℃)
			@850nm

			≤3.0dB/km
			≤3.0dB/km

			@1300nm

			≤1.0dB/km
			≤1.0dB/km

			@1310nm
			≤0.36dB/km

			@1550nm
			≤0.22dB/km

			Bandwidth(Class A)
			@850nm

			≥500MHz·km
			≥200MHz·km

			@1300nm

			≥1000MHz·km
			≥600MHz·km

			Numerical Aperture

			0.200±0.015NA
			0.275±0.15NA

			Cable Cut-off Wave length
			≤1260nm

Standards:
GYTC8S cable complies with Standard YD/T 769-2003.

Company Picture

Packaging Details

1.Wooden reel, 1000m/reel,2000m/reel,3000m/reel,customer's requirements are also welcomed;

2.Inner packed in fumigated wooden drum, and outer covered by polyethelene sheet,then sealed by strong wooden battens.

Delivery

For large orders: by sea (LCL or FCL)

For small orders: by sea (LCL), by air or by courier services(DHL ,UPS,TNT.....)
