LB-100 LCD display Portable Leeb Hardness Tester

Price Negotiable

Price: negotiation

MOQ: 1 Piece

Delivery Time: 3 working days

Brand: HARDRULER

Product Description

Features & Advantage

Wide measuring range in HL and direct display of converted hardness values in HRB, HRC, HV, HB and HS
For most metals (see table)
Provide testing at any angle, even upside down
High accuracy tolerance of maximum 0.8% on solid parts
Backlight LCD display showing all functions and parameters
Data output RS-232C
Optional printer available
Low battery indication
Auto-off after three minutes

Specification

Name	Portable Leeb Hardness tester
Model	LB-100
Hardness scales	HL, HRB, HRC, HV, HB, HS
Measuring range/metallic materials	200 ~ 900 HLD
Accuracy	± 0.8 % (HLD=800)
Statistics	Average value
Memory	50 groups
Output	RS-232C
Impact device	D(standard type)
Workpiece radius (convex/concave)	Rmin=50mm(with support ring Rmin=10mm)
Workpiece minimum weight	2.5kgon solid support(0.1kg with couplant paste)
Workpiece min. thickness coupled	3mm
Workpiece min.case hardned depth	0.8mm
Power	4*AAA battery 1.5V
Operating temperature	0ºC-50ºC
Humidity:	≤ 90 %
Dimension	120 × 62 × 30 mm
Weight	160g
