SC-LC 9m Armored Fiber Optic Cable Duplex Core Armoured Lan Cable
PVC Fiber Optic Patch Cord SC-LC-9m Duplex Core Single-Mode Armored Fiber Optic Cable
| Specifications | Unit | FC/SC/LC Armormed Patch cord | ST/MU | MT-RJ/MPO | E2000 | ||||||||
| Single Mode | Duplex Core | Single Mode | Duplex Core | Single Mode | Duplex Core | Single Mode | |||||||
| PC | UPC | APC | PC | PC | UPC | PC | PC | UPC | PC | PC | UPC | ||
| Insertion Loss | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 |
| Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥30 | ≥45 | ≥50 | ≥30 | ≥45 | ≥50 | ≥30 | ≥55 | ≥75 |
| Wavelength | nm | 1310;1510 | 1310;1510 | 1310;1510 | 1310;1510 | ||||||||
| Interchangeability | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | ||||||||
| Vibration | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | ||||||||
| Working Temperature | °C | -40~75 | -40~75 | -40~75 | -40~75 | ||||||||
| Storage Temperature | °C | -40~75 | -40~75 | -40~75 | -40~75 | ||||||||
| OD | mm | 3.0;2.0;0.9 | 3.0;2.0;0.9 | 3.0;2.0;0.9 | 3.0;2.0;0.9 | ||||||||
Product Image
Why Choose us?
a
Frequently Asked Questions:
Question 1: How long is the service life of the product?
Answer: Up to More than 5 years.
Question 2: Is the value of each jumper 100% tested?
Answer: Every optical fiber patch cord produced by our company is controlled in accordance with the ISO:9001 system, and the final production line is fully inspected to the testing process. The QC quality staff conducts the second sampling inspection of the finished product according to the corresponding rules to ensure that the test data is true and reliable.
Question 3: What should I do if there is a quality problem or there is a problem when using it on the device?
Answer: If confirmed it is the quality problems, not the false majeure or human factors, we will send you the same specifications and models free of charge in the fastest shipping method as soon as possible, so as not to delay the construction period.
