8-97945679-0 4JA1-TC Isuzu Clutch Disc 250*160*24*25.6
8-97945679-0 4JA1-TC 250*160*24*25.6 Clutch disc Isuzu Clutch Kits
This clutch disc OE number isuzu is 8-97945679-0 / 8-97944277-0. This Isuzu clutch kits outer diameter is 250mm, Inner diameter is 160mm,Hub profile is 25.6mm, and the number of teeth is 24. Suitable for engine 4JK1-TC / 4JJ1-TC,4JJ1E4C-L / 4JK1-TC,4JK1-TCX / 4JA1, Model Isuzu(import)D-MAX I (TFR, TFS) 2.5 DiTD (TFR86_) / Isuzu(import) D-MAX I (TFR, TFS) 2.5 DiTD 4x4 (TFS86_) / Isuzu(import) D-MAX I (TFR, TFS) 2.5 DiTD 4x4 (TFS86_) / Isuzu(import)D-MAX I (TFR, TFS) 3.0 DiTD 4x4 (TFS77H) / Isuzu(import)D-MAX I Platform/Chassis (TFR, TFS) 2.5 DiTD 4x4 / Isuzu(import) D-MAX II (TFR, TFS) 2.5 CRDi (TFR86J) / Isuzu(import) D-MAX II (TFR, TFS) 2.5 CRDi (TFR86J) / Isuzu(import) KB 2.5 D-TEQ / Isuzu(import) KB 2.5 DiTD / Isuzu(import) KB 3.0 DiTD.
Product Specification
| Item Name | Clutch disc / Isuzu Clutch Kits |
| Part number | 8-97945679-0 |
| Car Fitment | ISUZUD |
| Teeth | 24 |
| Engine | 4JA1-TC |
| Condition | New |
| Quality | 100% Tested |
| Outer Diameter | 250mm |
| Inner Diameter | 160mm |
| Hub Profile | 25.6mm |
ArtNum
| BLUE PRINT | ADZ93132 |
| EXEDY | ISD088U |
| HERTH+BUSS JAKOPARTS | J2209009 |
| JAPANPARTS | DF-909 |
| JAPKO | 80909 |
| MDR | MCD-1909 |
Used in Vehicle
| Model | Time | Engine | Displacement | Power | Type |
| Isuzu(import)D-MAX I (TFR, TFS) 2.5 DiTD (TFR86_) | 2006-2012 | 4JK1-TC | 2499 | 100 | Pickup |
| Isuzu(import) D-MAX I (TFR, TFS) 2.5 DiTD 4x4 (TFS86_) | 2002-2012 | 4JK1-TC | 2499 | 74 | Pickup |
| Isuzu(import) D-MAX I (TFR, TFS) 2.5 DiTD 4x4 (TFS86_) | 2007-2012 | 4JK1-TC | 2499 | 100 | Pickup |
| Isuzu(import)D-MAX I (TFR, TFS) 3.0 DiTD 4x4 (TFS77H) | 2002-2012 | 4JK1-TC | 2999 | 96 | Pickup |
Pictures
| 80909 |
