AC110V Vehicle Barrier Gate
AC110V Vehicle Barrier Gate
Automatic Remote Control Traffic Barriers Straight Rising Boom Barrier Gate System Road Barrier Gate Arm Traffic
Introduction:
A boom barrier is designed for a range of large opening up to 6m. It is ideal solution for controlling vehicle traffic in parking lots, private entrances, industrial and public uses.
As a manufacturer, we have more than 10 year experiences on designing, producing and installing boom barriers. The result is a superior boom barrier with best after after-sales service.
Quality control is our top priority, so we vigorously test our boom barriers to make sure a longer life span.
With our excellent craftsmanship, nice welding, galvanized and powder coated surface finishing, quiet and smooth during operation, our boom barriers can bring perfect user experience.
Applications:
Fast Barrier Gate adopts special machine core, swing away boom holder and boom. This barrier gate runs in high speed but stably. The running time is 1 second. It can be used for highway toll, parking system, factory gate, and so on.
Functions & Features:
A.The barrier works well with infrared photocells, loop detectors, card readers, ticket dispensers, manual switch (wire control), and traffic light
B.Barrier motor with die-casting aluminum alloy is high-hermetic and easy for heat dissipation
C.Motor cooling fan to avoid the over-heating possibility
D.Automatic reversing when the barrier boom meets the obstruction
E.Auto closing realization through menu setting on the control panel
F.RS485 Communication Module is compatible
G.Manual release device to operate the barrier when power failure
Advanced Functions
| Anti-collision protects boom arm |
| It will protect the boom arm not to be damaged once boom arm was collided by a vehicle |
| Safety--- Anti-hit by pressure resistance bounce |
| While moving down, boom arm will immediately go back to vertical position once it is obstructed by an imposed force, which protects the vehicle or person not to be hit by boom arm. The sensitivity is adjustable |
For security, the barrier will automatically go back when meet obstacles during closing.
Brushless DC motor is more powerful and no maintenance.
Beam can be chosen from 3 meters to 6 meters, and barrier closing time is also arranged from 1s to 6s.
The barrier can be installation both rightward and rightward.
All the operation process is soft without any noise and shaking.
Infrared photocell interface, Loop detector interface and IC system interface are reserved for the other functions.
Green light and red light are used inside for indication the position of the beam.
Manual release device to operate the barrier when power failure.
Barrier motor with die-casting aluminum alloy is high-hermetic and easy for heat dissipation.
Motor cooling fan to avoid the over-heating possibility.
Auto closing realization through menu setting on the control panel.
Wire control, remote control optional
Infrared protection (requires correlation infrared device)
Optional housing color: yellow, orange, white, red and blue etc.
Variable frequency controller automatically detects and optimizes boom moving, ensures
Specifications:
| Max LED boom & speed | 0.9s-2s | 3.5m |
| 1.5s-3s | 4.5m | |
| Opening and closing times | 0.9~3s | |
| Voltage | 220V/110V ±10% | |
| Frequency | 50HZ/60HZ | |
| Motor power consumption | 120W | |
| Motor consumption | 5 million times | |
| Working temperature | -30°to 80°℃ | |
| Housing dimension | 344(Width)*283(Depth)*1015(Height)mm | |
| Weight not including barrier boom | 50kgs | |
| Drive | Three-phase electric motor | |
| Maximum Remote Control Distance | ≤40m | |
