Steel Slitting 380v 600mm Coil Processing Lines
The best-selling steel slitting line industry technology leader
What is a steel slitting line?
The steel slitting line is to cut a large coil of steel coils into multiple narrower steel coils. The entire cutting process is a very precise continuous production process. Compared with other processes, it is the most accurate method for cutting metal coils. Ensure that each section of the cut steel coil meets your production needs.
Technical Parameters of Good use of The best-selling steel slitting line industry technology leader
| No. | Item | Specification |
| 1 | Formed Material | PPGI PPGL GI GL |
| 2 | Equipment operation | Automatic |
| 3 | Voltage | 380V 60Hz 3Phase or as your requirement |
| 4 | Thickness of sheet (mm) | 0.3-1.0mm |
| 5 | Material width(mm) | As your requirement |
| 6 | Cover Width of the sheet after formed | as your drawing |
| 7 | The size of the roll forming machine | about 3500mmx1300mmx1400mm |
| 8 | Speed | 15-20m/min |
| 9 | Diameter of shaft | 80mm |
| 10 | Weight of the Machine | 3000-3500KGS |
| 11 | Material of rollers | CR12 |
| 12 | Motor brand | Siemens or Guomao |
| 13 | PLC | Siemens or Delta or Mitsubishi |
| 14 | Total power (kw) | 11Kw |
| 15 | Power of hydraulic system | 4Kw |
| 16 | Power of main molding core | 4Kw |
| 17 | Rollers' material | 45# steel with chromn on the surface |
| 18 | Wall thickness of main forming machine | 16mm |
The production process of the steel slitting line?
The steel slitting line cuts the large coils of steel coils into small coils of different widths through the production processes of uncoiling, leveling, slitting, pressing, and winding.
In the whole production process, we only need to put the steel coil into the uncoiler and install it firmly, and then we can control the PLC electronic control device to start production. This process can be completed by only one person, which can help you save the cost of employment.
At the same time, the steel coils produced are accurate in size, and can be used in the next step of production or directly used for sales without secondary processing, which can help you quickly bring profits
