15m/Min Metal Forming Machine Solar Photovoltaic Channel Manufacturing

28000x3000 15m/min solar photovoltaic channel manufacturing machine

Process flow of solar photovoltaic channel manufacturing machine

Forming process: unwinding-guiding-forming-sizing, cutting-receiving

Configuration of solar photovoltaic channel manufacturing machine

1 Passive unwinding machine; 1 set

2 leveling machines; 1 set

3 servo feeder; 1 set

4 rotary punch; 1 set

6Middle plate and reducer of forming main machine: customized according to profile

7 hydraulic cut-off; 1 set

8 discharge table; 1 set

9 electrical control systems; 1 set

Parameters of solar photovoltaic channel manufacturing machine

Technical parameters of 18000x3000 15m/min solar photovoltaic channel manufacturing machine

Equipment performance

1 Sheet thickness: 1.5-2.5mm

2 Production line speed: 15m/min (adjustable)

3 Production area: 28 meters long X 3 meters wide

4 Total installed capacity: 25kw

Advantages of solar photovoltaic channel manufacturing machine:

1. The equipment is controlled by PLC, with multiple safety protections and one-key operation during normal production. To

2. The bed is welded by steel plate. It is also tempered to eliminate internal stress and avoid deformation of the fuselage, helping the stable operation of the solar photovoltaic channel manufacturing machine

3. The forming frame is a cast iron structure and has been tempered. High strength and long service life. To

4. The material of the forming mold is GCr15, quenched, and the hardness is HRC56-62℃. To

6. The transmission structure is gear box transmission. Each forming frame has a gear box, which can ensure the equipment overtime, high-strength operation, and long service life.
