Industrial-Grade HDMI Fiber Optic Extender 4K 60Hz Ultra HD Up to 10KM
Product Description:
This 4K HDMI optical extender enables seamless uncompressed transmission of HDMI 2.0b signals over a single-mode fiber line. It supports 18Gbps bandwidth, rich color depth at RGB 4:4:4, and audio I/O support. Perfect for integrators needing long-distance, interference-free 4K HDMI transport with RS-232 and EDID control, this HDMI over fiber extender is ideal for LED installations and control environments.
Key Features:
- 4K@60Hz max resolution (up to 4096x2160)
- Compatible with HDMI/DVI/3G/12G-SDI signal input
- EDID learning, CSC for non-standard displays
- WDM 4 or 8-channel transmission over one fiber
- Phoenix terminal for RS-232 integration
- Audio in/out for professional AV embedding
- IR pass-through for bidirectional remote control
Technical Parameters:
| Video | Supported Protocol | HDMI 2.0b |
| Video Bandwidth | 18Gbps | |
| HDCP | HDCP 2.2 | |
| Interface Bandwidth | 18Gbps | |
| Color Depth | RGB4:4:4 8-bit downward compatible | |
| Video Color Space | RGB4:4:4, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 | |
| Interface | HDMI-A interface | |
| Impedance | 100Ω | |
| Suggested Maximum HDMI Cable Input/Output Distance | Less than 10M. When the resolution is above 1920×1080@60Hz,it can reach 30M when using a cable with equalization. | |
| Audio | Audio Mode | Stereo |
| Audio Interface | 3.5mm stereo audio socket | |
| Audio Signal Type | Audio embedding and de-embedding | |
| RS232 | Interface | Phoenix Terminal |
| Signal Direction | Bidirectional Transmission | |
| Baud Rate | Default 38400bps, can be manually selected from 600-115200bps | |
| IR | IR Frequency | 38KHz |
| Optical Fiber | Optical Fiber Interface | LC Interface |
| Optical Fiber Type | Single -Mode | |
| Wavelength | TX1330/RX1270nm；TX1270nm/RX1330nm | |
| Interface Bandwidth | 10G | |
| Suggested Maximum Transmission Distance | Single-Mode Optical Fiber:10km | |
| Other | Power Supply | Single -circuit:DC 12V/1A |
| Maximum Power Consumption | Without KVM:max 4W;With KVM:max 6W | |
| Operating Temperature | 0°~40°C/32°F~104°F | |
| Humidity | 20~90% RH(No Condensation) | |
| Storage Temperature | -20°~60°C/-4°F~104°F | |
| Operating Time | 7*24 hours |
Applications:
This professional HDMI over fiber extender is an ideal solution for industries requiring stable, high-resolution video transmission, including broadcast media, corporate video conferencing, medical diagnostics, education livestreaming, and 24/7 surveillance systems. With full HDMI 2.0 support and resolutions up to 4K@60Hz.
- Stadium and large venue video distribution
- Data center and control room signaling
- Pro AV rack systems (1U/2U/3.5U configuration)
- Airport, exhibition, and surveillance systems
- Education, healthcare, and public broadcasting
- 4K@60Hz HDMI Fiber Optical Extender
![]()
