HDMI 4K Optical Extender Long Distance 4K HDMI Over Fiber Solution
Product Description:
This HDMI 4K Optical Extender is a professional-grade 4K HDMI over fiber solution designed to transmit ultra high-definition HDMI 2.0 signals over long distances of up to 10 kilometers using single-mode optical fiber. Supporting RS232 data transmission alongside video and audio, it ensures complete hdmi 4k extender functionality for modern AV needs.
Ideal for 4K HDMI optical extender applications in broadcasting, control rooms, medical imaging, and large-scale video displays, this hdmi 4k optical extender provides robust performance with easy plug-and-play installation.
Key Features:
- 4K Resolution Support: Supports up to 4K@60Hz video transmission, ensuring clear and detailed image quality.
- Long-Distance Transmission: Utilizes fiber optic technology to support signal transmission up to 10km or more, ideal for large venues or complex setups.
- Low Latency: High-efficiency fiber technology ensures almost zero latency, suitable for real-time applications.
- High Bandwidth Transmission: Supports up to 18Gbps bandwidth, ensuring stable transmission of high-quality video and audio signals.
- Strong Anti-Interference: Optical fiber transmission is immune to electromagnetic interference, ensuring stability in complex environments.
- Plug-and-Play: No additional drivers required, easy plug-and-play operation for convenience.
- Supports rack-mounted installation with 1U (4 cards)
Technical Parameters:
| Video | Supported Protocol | HDMI 2.0b |
| Video Bandwidth | 18Gbps | |
| HDCP | HDCP 2.2 | |
| Interface Bandwidth | 18Gbps | |
| Color Depth | RGB4:4:4 8-bit downward compatible | |
| Video Color Space | RGB4:4:4, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 | |
| Interface | HDMI-A interface | |
| Impedance | 100Ω | |
| Suggested Maximum HDMI Cable Input/Output Distance | Less than 10M. When the resolution is above 1920×1080@60Hz,it can reach 30M when using a cable with equalization. | |
| Audio | Audio Mode | Stereo |
| Audio Interface | 3.5mm stereo audio socket | |
| Audio Signal Type | Audio embedding and de-embedding | |
| RS232 | Interface | Phoenix Terminal |
| Signal Direction | Bidirectional Transmission | |
| Baud Rate | Default 38400bps, can be manually selected from 600-115200bps | |
| IR | IR Frequency | 38KHz |
| Optical Fiber | Optical Fiber Interface | LC Interface |
| Optical Fiber Type | Single -Mode | |
| Wavelength | TX1330/RX1270nm；TX1270nm/RX1330nm | |
| Interface Bandwidth | 10G | |
| Suggested Maximum Transmission Distance | Single-Mode Optical Fiber:10km | |
| Other | Power Supply | Single -circuit:DC 12V/1A |
| Maximum Power Consumption | Without KVM:max 4W;With KVM:max 6W | |
| Operating Temperature | 0°~40°C/32°F~104°F | |
| Humidity | 20~90% RH(No Condensation) | |
| Storage Temperature | -20°~60°C/-4°F~104°F | |
| Operating Time | 7*24 hours |
Applications:
This 4k HDMI optical extender and HDMI 4k optical extender is perfect for:
✅ Broadcasting studios and control rooms
✅ Medical imaging systems
✅ Video conferencing setups
✅ Digital signage and exhibitions
✅ Educational and training facilities
✅ Government and command centers
✅ Home theaters and multi-screen environments
The advanced HDMI 4k extender ensures crisp, lag-free 4K content delivery across large distances, making it an essential tool for any demanding AV environment.
