BS 70A Railway Fishplate Adhering to British Standards for Optimal Performance
BS 70A Railway Fishplate
The BS 70A Railway Fishplate, also known as a rail joint bar or splice bar, is crucial for connecting and stabilizing adjacent rail sections in railway system. The BS 70A Railway Fishplate is specifically designed for use with BS 70A rail sections, adhering to British Standards. This fishplate serves as a vital component in railway infrastructure, connecting two rail ends to ensure proper alignment and stability at the joint. We emphasize rigorous quality control in our manufacturing process. Our fishplate production adheres to the ISO9001-2015 quality standard, and we hold a certified railway product manufacturing license. Using professional testing equipment, we guarantee that every fishplate meets customer requirements. Feel free to contact us.
BS 70A Railway Fishplate specification
| Specifications | Length of 4-bolt fishplate (mm) | Length of 6-bolt fishplate (mm) | Diameter of bolt holes in fish plates (mm) | (kg) |
Calculated weight per pair (6 hole) (kg) |
| BS70A | 406.4 | 609.6 | 23.81 | 11.10 | 16.65 |
BS 70A Railway Fishplate technical parameters
| Fishplate for BS Standard Steel Rail | |||
| BS50'O' | 24.833 | BS 47-1 | 55#,45# European Grade 700 |
| BS60A | 30.618 | ||
| BS75R | 37.041 | ||
| BS80A | 39.761 | ||
| BS90A | 45.099 | ||
| BS100A | 50.182 | ||
| BS113A | 56.398 | ||
| Joint Bar for AREMA 2007 Standard Steel Rail | |||
| 100RE(TR50) | 50.35 | AREMA 2007 | 45#,55#, AREMA Grade Steel |
| 115RE | 56.9 | ||
| 115-119RE | |||
| 132RE | 65.31 | ||
| 133RE | 66.1 | ||
| 136RE | 67.41 | ||
| 132-136RE | |||
BS 70A Railway Fishplate workshop
