S960 S960Q S960QL S960QL1 High Strength Steel Plate Thickness 16 mm Low Alloy
S960 low alloy steel is a European standard quenched and tempered high yield strength structural steel. "S" stands for structural steel, "960" means the yield strength is not less than 960MPa, and "Q" means the delivery state is quenched and tempered (quenched + tempered).
S960 low alloy steel material has good plasticity, toughness and excellent weldability. The S960 high strength low alloy steel provided by GNEE to customers can be customized in size according to needs. S960 high strength low alloy plate can be used in multiple industries.
Engineering application fields of S960 high strength steel
Bridge engineering: used for large bridge construction, such as suspension bridges, cable-stayed bridges, etc.
Building structure: used in high-rise buildings, large factories, etc.
Heavy machinery: manufacturing heavy machinery and equipment such as excavators, loaders, cranes, etc.
| EN10025-6 Steel Plate Chemical Composition | ||||||||
| Grade | Quality | C | Mn | Si | P | S | N | Other Elements |
| All grades | No symbol | 0.22 | 1.80 | 0.86 | 0.030 | 0.017 | 0.016 | Cr 1.60, B 0.006, Cu 0.55,
Mo 0.74, Nb 0.07, Ni 4.10, Ti 0.07, V 0.14, Zr 0.17 |
| L | 0.22 | 1.80 | 0.86 | 0.025 | 0.012 | 0.016 | ||
| L1 | 0.22 | 1.80 | 0.86 | 0.025 | 0.012 | 0.016 | ||
| EN10025-6 Steel Plate Yield Strength Min. (Mpa) | ||||
| Thickness (mm) | 3-50mm | 50-100mm | 100-125mm | 125-200mm |
| S960Q/S960QL/S960QL1 | 960Mpa | 850Mpa | 850Mpa | |
| EN10025-6 Steel Plate Tensile Strength and Elongation | |||||
| EN 10025-6 | Tensile | Tensile | Tensile | Tensile | Elongation |
| Grade | Mpa | Mpa | Mpa | Mpa | After fracture |
| Thickness (mm) | 3-50mm | 50-100 | 100-125 | 125-200 | |
| S960Q/S960QL/S960QL1 | 980-1150 | 900-1100 | 900-1100 | ≥10% | |
