A537 Class 1 Plates 15mo3 16mo3 Pressure Vessel Steel Plate Astm A537 Class 1 Low Alloy Steel Plate
A537 Class 1 Plates 15mo3 16mo3 Pressure Vessel Steel Plate Astm A537 Class 1 Low Alloy Steel Plate
| Technique | Hot rolled/cold rolled |
| Thickness | 8-30mm |
| Width | 10-3000mm |
| Normal width | 1200mm-3500mm |
|
Surface
|
black, galvanized,, fingerprint resistant treatment, slight oiled or non-oiled, dry,as customers required |
ASTM A537 CL.1 steel plates shall be normalized. SA537CL2 and SA537Cl3 plates shall be quenched and tempered. ASTM A 537 Class 1 carbon steel plates are engineered to be used in pressure vessel applications. The material is a normalized steel which is heat treated and as a consequence displays greater yield and tensile strength than the more standard ASTM A516 grades.
|
A537 class 1 Chemical Composition |
|||||||||
|
Grade |
The Element Max (%) |
||||||||
|
C |
Mn |
P |
S |
Si |
Cu |
Ni |
Cr |
Mo |
|
|
A537 class 1 |
0.24 |
0.92-1.72 |
0.035 |
0.035 |
0.13-0.55 |
0.38 |
0.28 |
0.29 |
0.09 |
|
Grade |
A537 class 1 Mechanical Property |
|||
|
Thickness |
Yield |
Tensile |
Elongation |
|
|
A537 class 1 |
mm |
Min Mpa |
Mpa |
Min % |
|
-65 |
345 |
485-620 |
22 |
|
|
65-100 |
310 |
450-585 |
- |
|
|
100-150 |
- |
- |
18 |
|
Stockists of ASME SA537 Class 1 Carbon Steel Plates in Tianjin, A537 CL. 1 Boiler Plate, ASME SA537 Class 1 Plate, ASTM A537 Class 1 Pressure Vessel Plates Suppliers
Advantages of A537 Class 1 Plates
- These plates offers great resistivity to corrosion
- Any chance of leakages are negligible
- Tendency to bear maximum pressure with minimum elongation
- Increase the service of pressure vessels
- Improves the surface finish of vessels
- There is no chance of reaction inside the container
- Provides the maximum strength to pressure vessels
- Made to work at Low Temperature Services Up to Minus 46 Degree.
