Astm A285 GR A Pvq Steel Plate Astm A285 Pressure Vessel Plates Astm A285 Carbon Steel
Astm A285 GR A Pvq Steel Plate Astm A285 Pressure Vessel Plates Astm A285 Carbon Steel
| Brand name | Gnee |
| Length | 6000-18000mm |
| Width | 1250mm-4000mm |
| Thickness | 12-400mm |
| Tolerance | Standard tolerance |
| Standard | GB,AISI,ASTM,JIS,DIN,API |
| Technical | Hot rolled |
| Surface | Coated |
| Application |
Adapted to the electric power tower, all kinds of lifting crane, heavy duty truck, oil , high temperature fan, large power shovel, dump truck, and drilling machine, hydraulic support in coal mine, steel structure, etc |
A285GrA Vessel Steel Plate ASTM A285 standard specification for pressure vessel plates, carbon steel, low- and intermediate-tensile strength. ASTM A285 plates are normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both.
ASTM A285 grade A is a type of ASTM A285 carbon steel. Cited properties are appropriate for the as-fabricated (no temper or treatment) condition. It has the lowest strength and highest ductility compared to the other variants of ASTM A285 carbon steel.
The graph bars on the material properties cards below compare ASTM A285 grade A to: wrought carbon or non-alloy steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
Width: 600-3500mm
Thickness: 15mm-300mm
Length: As requested
Width tolerance: different as per different width
Thickness tolerance: different as per different thickness
Weight: According to the different requirement
ASTM A285 PVQ Steel Plate
|
A285 grade A Chemical Composition |
|||||
|
Grade |
The Element Max (%) |
||||
|
C |
Si |
Mn |
P |
S |
|
|
A285 grade A |
0.17 |
0.08-0.45 |
0.98 |
0.035 |
0.035 |
|
Grade |
|
A285 grade A Mechanical Property |
||
|
Thickness |
Yield |
Tensile |
Elongation |
|
|
A285 grade A |
mm |
Min Mpa |
Mpa |
Min % |
|
6-50 |
165 |
310-450 |
30% |
|
|
50-200 |
165 |
310-450 |
27% |
|
