ASTM A 285/A283 Grade C Sheets and Plates, A285 Gr.C Boilers plates, ASME A 285 / A283 Grade C Sheets and Plates Pressure Vessel Steel Plate Exporters, Suppliers and Stockists in China. A285/ A283 Grade C Sheets and Plates
ASTM A285 standard is for carbon steel, low and intermediate tensile strength steel plates intended for fusion-welded pressure vessels.
| Name | Steel Plate |
| Thickness | 8mm-200mm |
| Diameter | As your require |
| Delivery condition | Hot rolled, controlled rolled, or normalized |
| Cutting service | Large steel plate cut to flat plate sizes, or cut to any size by drawing |
| Deep processing |
After cutting large plate into the general sizes by drawing, milling and grinding, and make angles, polishing, and make special parts |
A285 GrC STEEL PLATE
ASTM A285 Grade C steel plate is found throughout industry in a wide range or low pressurized applications.ASTM A285 Grade C steel plate is used in a range of other applications including structural,mechanical and general engineering purposes
ASTM A285 Grade C Carbon Steel Plates Specification
| ASTM A285 Grade C Plate Standard | JIS,GB, BS, ISO and So on |
|---|---|
| ASTM A285 Grade C Steel Plates Heat Treatment | Hot Rolled, CR, Normalized, Quenched, Tempering, TMCP, Electroslag Remelting Technical |
A285 GrC STEEL PLATE Chemical Composition: %
|
|
Grade B |
Grade C |
|
Carbon, maxA |
0.22 |
0.28 |
|
Manganese, max Heat analysis |
0.90 |
0.90 |
|
Product analysis |
0.98 |
0.98 |
|
Phosphorus, maxA |
0.025 |
0.025 |
|
Sulfur, maxA |
0.025 |
0.025 |
A285 GrC STEEL PLATE Mechanical Property
| Thickness | Yield | Tensile | Elongation |
| mm | Min Mpa | Mpa | Min % |
| 6-50 | 205 | 380-515 | 27% |
| 50-200 | 205 | 380-515 | 23% |
| Packaging | when each plate weight is under 1 ton, it will be in bundle with steel strips 2-4, when each plate weight is over 1ton, it will be piece by piece. |
| 20 feet container contains dimension | Width under 2300mm, length under 6000mm |
| 40 feet container contains dimension | Width under 2300mm, length under 12000mm |
| By bulk vessel | Freight charge is low by bulk cargo, and large heavy sizes can not be loaded into containers can shipping by bulk cargo |
