A514 Gr F Steel Plate A514 Hot Rolled Steel Sheet High Strength High Tensile Astm A514 Steel Plate
A514 Gr F Steel Plate A514 Hot Rolled Steel Sheet High Strength High Tensile Astm A514 Steel Plate
| Thickness | 2-200mm | |||
| Width | 1000-3000mm | |||
| Length | 1000-12000mm | |||
| Surface | Clean, finishing,blasting and painting according to customer requirement | |||
| Delivery States |
Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T,and other delivery states are available as required |
|||
| Certificate | API,ISO,SGS,BV,CE etc | |||
| Quality | MTC will be provided with goods, third part inspection is acceptable, for example BV,SGS. |
|||
| Package | Standard export seaworthy package,suit for all kinds of transport, or as required. |
|||
ASTM A514 GR.F plates are normally supplied in the as-rolled condition.The plates may be ordered normalized or stress relieved, or both. ASTM A514 GR.F steel plates shall be ASTM A514 GR.Fplate is High-Yield-Strength, Quenched and Tempered Alloy Steel Plate, Suitable for Welding. ASTM A514 GR.F plates shall be Quenched and Tempered.
A514 Grade F Chemical Composition Max (%)
| A514 Grade F | C | Mn | P | S | Si | Ni | Cr | Mo | V | Ti | Zr | Cu | B | Nb |
| 0.10-0.20 | 0.60-1.00 | 0.035 | 0.035 | 0.15-0.35 | 0.70-1.00 | 0.40-0.65 | 0.40-0.60 | 0.03-0.08 | - | - | 0.15-0.50 | 0.001-0.005 | - |
A514 Grade F Mechanical Property
| Grade | Thickness | Yield | Tensile | Elongation |
| A514 grade F | mm | Min Mpa | Mpa | Min % |
| 20 | 690 | 760-895 | 18 | |
| 20-65 | 690 | 760-895 | 18 | |
| 65-150 | 620 | 690-895 |
18 |
|
Equipment
|
Laser cutting machine
CNC hydraulic punching machine Bending machine, Shearing machine |
||
|
Market
|
We are not only one of the domestic biggest supplier,we also export to all over the word.
|
||
|
Size
|
We can produce special specifications of steel products according to orders.
Our production process strictly conforms to the international standard of DIN/ASTM/AISI /JIS/BS to ensure the quality. |
||
|
Shape
|
We can procss according to your drawing.
|
||
FAQ
Q1. Where is your factory ?
A1: Our company’s processing center is located in Tianjin, China.
Which is well equipped with kinds of machines, such as laser cutting machine,mirror polishing machine and so on.
We can provide a wide range of personalized services according to the customers’ needs.
A2: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
A5: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7days.
