ASTM A517 standard specification for pressure vessel plates, alloy steel, high-strength, quenched and tempered. The steel shall be killed and shall conform to the fine austenitic grain size requirement of Specification A20/A20M.
|
Thickness |
6mm, 8mm, 12mm, 16mm, 20mm, 25mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm |
|
Width: |
1500mm, 1800mm, 2000mm, 2200mm, 2500mm |
|
Length: |
6000mm, 8000m, can cut to width and length |
|
Packing Details; |
according to customer's require or export's standard |
|
Delivery Time; |
7 days for stock sizes, 20-25 days for new production sizes |
|
Port: |
Tianjin China |
A517 GRADE Q Chemical composition % of the Product analysis of grade
|
Grade |
C % |
Si % |
Mn % |
P % |
S % |
V % |
AL % |
Cr % |
|
A517 GRADE Q |
0.12-0.23 |
0.13-0.37 |
0.87-1.41 |
0.035 |
0.035 |
|
|
0.94-1.56 |
|
Cu % |
Mo % |
Nb % |
Ni % |
Ti % |
Tungsten |
|
|
|
|
|
0.36-0.64 |
|
1.15-1.55 |
0.07 |
|
|
|
A517 GRADE Q Mechanical Property
|
Grade |
Thickness(mm) |
Min Yield |
Tensile |
Elongation |
Min Impact Energy |
|
|
A517 GRADE Q |
6-65 |
690 Mpa |
795-930 Mpa |
16 % |
|
|
|
65-150 |
620 Mpa |
725-930 Mpa |
14 % |
|||
Application of A517 Grade A steel plate:
A517 grade A steel plate is the Specification for Pressure Vessel Plates, High-Strength, Alloy Steel, Quenched and Tempered material suitable to use in the boilers and pressure vessels application.Typical applications include unfired vessels and tanks.
1.Delivery: Within 7-30 days after the confirmation of the order
2.Transport cargo to port by truck and will covered on the road and also covered at port.
3.Shipping by bulk or container
Service
1 .can cut the large steel plates by your requirements
2 .can make the surface of the cut steel plate to be bright by miling and grinding
3 .can make holes and make angle degrees,and can weld by your drawing.
Q: Are you trading company or manufacturer ?
A: We are trading company
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
