20MnMoNi4-5 Steel Plate 20MnMoNi4-5 Hot Rolled Steel Sheet 20MnMoNi4-5 Hot Rolled Steel Plates
20MnMoNi4-5 Steel Plate 20MnMoNi4-5 Hot Rolled Steel Sheet 20MnMoNi4-5 Hot Rolled Steel Plates
| Description | Alloy Steel Plate | ||
| Related Material |
20MnMoNi4-5 |
||
| Specifications | Thickness:5mm-120mm | ||
| width :1-4 meters . | |||
| Length:1-12 meters . | |||
| Price Term | EX-Work, FOB, CFR, CIF | ||
20MnMoNi4-5 steel gradeis one of grade in En10028-2, which is non alloy and alloy steelswith specified elevated temperature properties. In accordance with en10020, 20MnMoNi4-5 steel grade is alloy special steels. 20MnMoNi4-5 Gradedelivery condition is normalized and tempered or quenched and tempered.
20MnMoNi4-5 Chemical Composition Max (%)
| Grade | C | Si | Mn | P | S | Al(min) | N |
| 20MnMoNi4-5 | 0.15-0.23 | 0.40 | 1.0-1.50 | 0.020 | 0.010 | 0.012 | |
| Cr | Cu | Mo | Nb | Ni | Ti | V | |
| 0.20 | 0.20 | 0.45-0.60 | 0.4-0.80 | 0.02 |
20MnMoNi4-5 Mechanical Property
| Grade | |||||||
| Thickness | Yield | Tensilmie | Elongation | Impact Energy(KV J) min | |||
| 20MnMoNi4-5 | mm | Min Mpa | Mpa | Min % | -20° | 0° | +20° |
| ≤ 40 | 470 | 590-750 | 18 | 27 | 40 | 50 | |
| 40> to ≤60 | 460 | 590-730 | 18 | 27 | 40 | 50 | |
| 60> to ≤100 | 450 | 570-710 | 18 | 27 | 40 | 50 | |
| 100> to ≤150 | 440 | 570-710 | 18 | 27 | 40 | 50 | |
| 150> to ≤250 | 400 | 570-710 | 18 | 27 | 40 | 50 | |
| STANDARD |
GB/T 3522,GB/T 3524,GB/T 13237,GB/T 16270,GB712,GB713, YB/T 055,GB6653,GB/T 11251,GB713,GB3531,GB6654,GB19189, A202A/A202M,A203/A203M,A204/A204M,A225/A225M,A285/A285M, A299/A299M,A302/A302M,A353/A353M,A387/A387M,A455/A455M, A662/A662M,A724/A724M,A734/A734M,A735/A735M,A736/A736M, A737/A737M,A738/A738M,A515/A515M,A516/A516M,A517/A517M, A533/A533M,A537/A537M,A542/A542M,A543/A543M,A553/A553M, A562/A562M,A612/A612M,A645/A645M,A662/A662M,A738/A738M, A782/A782M,A832/A832M,A841/A841M,A844/A844M,JIS G3118, JIS G3115,JIS G3103,JIS G3116,JIS G3126,JIS G3124,JIS G3127, JIS G4109,JIS G4110,JIS G3119,JIS G3120,JIS G3101,JIS G3106, JIS G3114,JIS G3125,,DINEN 10120,DIN17460,DINEN 10028, EN10025-2-2004,EN10028-2-2003,etc |
| MATERIAL |
GB 15,20,25,30,35,40,45,50,55,60,65,70,Q195,Q215,Q235,Q255,Q275,Q295, Q345,08F,10F,15F,08,08Al,10,Q420,Q460,Q500,Q550,Q620,Q690,A32, D32,E32,F32,A36,D36,E36,F36,A40,D40,E40,F40,20G,22MnG,LT,XT1, XT2,HP245,HP265,HP295,HP325,HP345,HP365,45Mn2,27SiMn,40B, 45B,50B,15Cr,20Cr,15CrMoG,16MnG,19MnG,13MnNiCrMoNbG, 12Cr1MoVG,16MnDR,15MnNiDR,09MnNiDR,20R,16MnR,15MnNbR, 15MnVR,15MnVNR,18MnMoNbR,13MnNiMoNbR,15CrMoR, 07MnCrMoVR,07MnNiMoVDR,12MnNiVR,etc |
|
ASTM ASTM A414/A414M A/B/C/D/E/F/G,ASTM A515/A515M 415/450/485, ASTM A516/A516M 380/415/450/485,ASTM A204/A204M A/B/C, ASTM A537/A537M 1/2/3,ASTM A202/A202M A/B ASTM A203/A203M A/B/D/E/F,ASTM A225/A225M C/D, ASTM A737/A737M B/CASTM A353/A353M, ASTM A387/A387M 2/12/11/12/22L/21/21L/5/17/9/91, ASTM A517/A517M A/B/C/E/F/H/J/M/P/Q/S/T, ASTM A533/A533M A/B/C/D, ASTM A542/A542M A/B/C/D/E,ASTM A543/A543M B/C, ASTM A782/A782M,ASTM A844/A844M,etc |
|
|
JIS SGV410,SGV450,SGV480,SPV235/315/355/410/450/490,SB410/450/480, SG255,SG295,SG325,SG365,SLA235A/235B/325A/325B/365/410, SB450M/480M,SQV3A/3B,SEV245/295/345,SL2N255,SL3N255/275/440, SL5N590,SL9N520/590,SCMV1/2/3/4/5/6,SCMQ4E/4V/5V, SBV1A/1B/2/3,SQV1A/1B/2A/2B,SS330,SS400,SS490,SS540, SM400A/400B/400C/490A/490B/490C/490YA/490YB/520B/520C/570, SMA400AW/400AP/400BW/400BP/400CW/400CP/490AW/490AP/490B W/490BP/490CW/490CP/570W/570P,SPA-H,SPA-C,etc |
|
|
DIN P245NB,P265NB,P310NB,P355NB,X6CrNi1811,X3CrNiN1811, X8CrNiTi1810,X6CrNiMo1713,X3CrNiMoN1713,X8CrNiNb1613, X8CrNiMoNb1616,X8CrNiMoVNb1613,X5NiCrAlTi3120, X8NiCrAlTi3221,X5NiCrAlTi3120RK,P235GH,P265GH,P295GH, P355GH,16Mo3,13CrMo4-5,10CrMo9-10,11CrMo9-10,etc |
|
|
EN S185(1.0035),S235J0(1.0114),S235JR(1.0038),S235J2(1.0117), S275JR(1.0044),S275J0(1.0143),E295,S355J0(1.0553),E335(1.0060), S235J2W(1.8961),S355J2W(1.8965),P235GH,P265GH,P295GH,P355GH, 16Mo3,13CrMo4-5(1.7335),10CrMo9-10,12Ni14,X12Ni5,X8Ni9,etc |
1. We are a specialized manufacturer. Competitive price and quality from our own factory .
2. Best service with 24 hour`s reply .
3. Flexible payment with T/T,L/C , etc .
4. Smooth production ability(1000tons/month).
5. Quick delivery and standard exporting package .
Q: Can you provide EN10204 3.2 MTC?
A: Yes.
Q: Can we get sample?Any charges?
A: Yes,you can get available samples in our stock. Free for real samples, but customers need to pay the freight cost.
Q: How can we get the offer?
A: Pease submit the required steel grade, size, quantity. And we will check price for you at the first time.
Q. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, etc
Q. What is your sample policy?
A: We can supply free samples if we have ready parts in stock, but the courier cost are charged.
Q: Are you trading company or manufacturer ?
A: We are factory, have our own trading department.
