Crgo Silicon Steel Coil Strip Power Transformers Baowu Steel 0.65mm
Crgo Silicon Steel Coil Strip Power Transformers Baowu Steel 0.65mm
B50AR350 magnetic flux density is not less than the peak B50 T% stacking factor of not less than: 96 inorganic coating D has good heat resistance and weldability A semi-organic thin coating to improve the punching resistance, and good weldability and a half thick organic H coating punching good interlaminar high resistance chrome-free coating K coating does not contain hexavalent chromium, it has good weldability.
B50AR350 steel mechanical Properties:
| Grade | tensile strength L(N/mm2) |
Yield Strength L(N/mm2) |
Elongation L(%) |
Hardness HV1 |
Bending frequency (times) | Stacking factor(%) | tensile strength L(N/mm2) |
| B50AR350 | 0.50 | 7.80 | 382 | 260 | 38 | 125 | ≥15 |
electromagnetic performance standards:
| Grade | Nominal thickness(mm) | Theoretical density(kg/dm3) | Maximum core loss P17/50 (W/kg) |
The minimum magnetic induction B8 (T) |
| B50AR350 | 0.50 | 7.80 | 3.50 | 1.74 |
FAQ
Q: Would you provide samples For free?
A: Yes . with on stock specification We provide samples For Free . Freight charge collect.
Q:What information should i provide to source for the right products ?
A: Material grade, width, thickness, coating and Purchase quantity , Expected lead time ,etc.
Q: About product prices?
A: Prices vary from period to period due to cyclical changes in the price of raw materials.
