OWB9290B-24V 92*90mm Brushless DC Air Blower With 12Kpa High Pressure For Ventilatros and Inflatables
OWB9290B-24V Blower parameters:
| Model | OWB9290B-24V-220 |
| Voltage | 24VDC |
| At Free Blowing | |
| Speed | 22500±10%rpm |
| Current | 7.8±10%A |
| Air Flow | 47±10%m³/h |
| At Static Pressure | |
| Speed | 28500±10% rpm |
| Current | 5.2±10% A |
| Air Pressure | 12.5±10% Kpa |
| At Working Point | |
| Air Pressure | 8.0Kpa |
| Speed | 25500±10%rpm |
| Current | 7.7±10%A |
| Air Flow | 25±15%m³/h |
Drawing:
P-Q Performance Curve:
Wiring Diagram for Driver Controller:
Package:
Applications:
1: Buffer air cushion
2: Intelligent closestool
3: Electric-Drive phlegm-Sucker
4: Central ventilation system
5:Air purifier
6:Hand dryer
7: Air bubble machine
8: Ventilating device
9: Vacuum cleaner
10: breathing machine
11: air pump
12: Cooling equipment
Brushless DC Air Blower Features:
High pressure and airflow output by compact size design
High reliability, specialized controller make the working more reliable
High intelligent, PWM speed regulation, positive inversion, PG signal feedback, intelligent controlling
