7079864410 Blade Tilt Cylinder Seal Kit For D135A-1 D155A-5 Komatsu Tilt Dozer
Price:
Negotiation
MOQ:
Trial order acceptable
Delivery Time:
3-5 days after payment received(public holiday excluded)
Brand:
SUNCAR
Product Description
7079864410 Blade Tilt Cylinder Seal Kit For D135A-1 D155A-5 Komatsu Tilt Dozer
| Product Name | Cylinder Seal Kit |
| Model Number | Komatsu D135A-1, D135A-2, D155A-3, D155A-5, D155AX-3, D155AX-5 |
| Place of Origin | China(Mainland) |
| Brand name | SUNCAR |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.) |
| Part Number | 7079864410 |
| Payment Terms | Western Union, L/C, T/T, Money Gram, D/A, D/P |
| Size | Standard size |
| Applicable Industries | Construction works, machinery repair shops, retail, other |
| CertifiC.A.Tion | ISO9001 |
| Condition | 100% new |
| C.A.Tegory | Seal kits |
| Warranty | Unavailable |
| OEM and ODM | Welcome |
| Feature | Oil & high pressure & high temperature resistant |
| Preservation Notice | Closed, dry and avoid the sun |
| AppliC.A.Tion | Komatsu bulldozers |
| Cylinder Number | 15A-63-02130, 17A-63-02110, 17A-63-02130 |
| Rod | 90MM |
| Bore | 180MM |
Related Parts:
| Pos. | Part No | Qty | Parts name |
| G-1 | 707-04-XZ060 | [1] | CYLINDER GROUP,(FINAL COATING) |
| G-1 | 17A-63-X2131 | [1] | CYLINDER GROUP |
| 707-04-00050 | [1] | CYLINDER ASSEMBLY | |
| 17A-63-02131 | [1] | CYLINDER ASSEMBLY | |
| 1 | 17A-63-52141 | [1] | CYLINDER |
| 2 | 195-63-52160 | [1] | BUSHING |
| 3 | 707-27-18830 | [1] | HEAD,CYLINDER |
| 3 | 707-27-18520 | [1] | HEAD,CYLINDER |
| 4 | 707-52-90680 | [1] | BUSHING |
| 4 | 707-52-10910 | [1] | BUSHING Komatsu |
| 5 | 707-51-90030 | [1] | PACKING,ROD (KIT) |
| 5 | 707-51-90211 | [1] | PACKING,ROD (KIT) |
| 5A | 707-51-90640 | [1] | RING,BUFFER (KIT) |
| 6 | 707-56-90740 | [1] | SEAL,DUST (KIT) |
| 7 | 07179-13104 | [1] | RING,SNAP |
| 8 | 07000-15170 | [1] | O-RING (KIT) |
| 9 | 07146-05172 | [1] | RING,BACK-UP (KIT) |
| 10 | 01010-81865 | [12] | BOLT |
| 11 | 01643-31845 | [12] | WASHER |
| 12 | 15A-63-52120 | [1] | ROD,PISTON |
| 13 | 707-36-18400 | [1] | PISTON |
| 14 | 07000-12070 | [1] | O-RING (KIT) |
| 15 | 707-35-52910 | [2] | RING,BACK-UP (KIT) |
| 16 | 707-44-18180 | [1] | RING,PISTON (KIT) |
| 17 | 07156-01822 | [1] | RING,WEAR (KIT) |
| 18 | 707-40-18070 | [2] | SPACER |
| 19 | 01010-61240 | [6] | BOLT |
| 20 | 15A-71-12150 | [1] | TUBE |
| 21 | 15A-71-12160 | [1] | TUBE |
| 22 | 07000-13030 | [1] | O-RING (KIT) |
| 23 | 07000-13025 | [1] | O-RING (KIT) |
| 24 | 01010-80840 | [2] | BOLT |
| 25 | 01010-80855 | [2] | BOLT |
| 26 | 01010-80835 | [2] | BOLT |
| 27 | 01010-50845 | [2] | BOLT |
| 28 | 01643-30823 | [8] | WASHER |
| 29 | 195-63-52871 | [1] | CLIP |
| 30 | 01010-81420 | [1] | BOLT |
| 31 | 01643-31445 | [1] | WASHER |
| 32 | 17A-63-52191 | [1] | COVER |
| 33 | 01010-81635 | [6] | BOLT |
| 34 | 01643-31645 | [6] | WASHER |
| 35 | 154-63-52890 | [2] | PLUG,(FOR SHIPPING) |
| 707-99-64550 | [1] | SERVICE KIT | |
| 707-98-64410 | [1] | SERVICE KIT |
