Komatsu Repair Kit 707-99-64130 Hydraulic Lift Cylinder Seal Kit Fits WA420-3 Wheel loader equipment
Komatsu Repair Kit 707-99-64130 Hydraulic Lift Cylinder Seal Kit Fits WA420-3 Wheel Loader Equipment
| Komatsu Repair Kit 707-99-64130 Hydraulic Lift Cylinder Seal Kit Fits WA420-3 Wheel Loader Equipment | |||
| Model No. | Komatsu WA420-3 | Packing | PP bag,Carton,Wooden case or as Required |
| Material | Rubber,PTFE,NBR,PU | MOQ | 1pcs |
| Size | Standard size or custom size | Brand | Suncar |
| Hardness | 70-95 Shore A | Temperature | -35~220℃ |
| Pressure | 0~0.05Mpa | Feature | Oil-resistant, heat resistant,Durable |
| Color | Black Brown Bule yellow and more | Loading Port | Huangpu port in China |
| AppliC.A.Tion | Hydraulic cylinder seal kit | Payment terms | T/T, Western union, paypal, |
| trade assurance or as require | |||
| CertifiC.A.Tes | ISO9001 | Delivery time | Within 5-7 days |
| Warranty | Unavailable | Shipment | By sea, by air, by express or as required |
Related Parts:
| Pos. | Part No | Qty | Parts name | Comments |
| 707-01-03570 | [2] | CYLINDER.ASSEMBLY.LIFT | ||
| 707-01-03082 | [2] | CYLINDER.ASSEMBLY.LIFT | 168.001 kg. | |
| 1. | 707-13-16251 | [1] | CYLINDER | |
| 2. | 707-76-95040 | [1] | BUSHING | 1.3 kg. |
| 3. | 707-27-16380 | [1] | HEAD.CYLINDER | 10.8 kg. |
| 4. | 707-52-90680 | [1] | BUSHING | 0.165 kg. |
| 5. | 707-51-90030 | [1] | PACKING.ROD | 0.048 kg. |
| 6. | 195-63-94170 | [1] | SEAL.DUST | 0.053 kg. |
| 7. | 07179-13104 | [1] | RING.SNAP | 0.022 kg. |
| 8. | 07000-15150 | [1] | O-RING | 0.016 kg. |
| 9. | 07146-05152 | [1] | RING.BACK-UP | 0.011 kg. |
| 10. | 01010-81660 | [12] | BOLT | 0.127 kg. |
| 11. | 01643-51645 | [12] | WASHER | 0.021 kg. |
| 12. | 707-59-90222 | [1] | ROD.PISTON | 85.001 kg. |
| 13. | 07000-12070 | [1] | O-RING | 0.03 kg. |
| 14. | 707-35-52910 | [2] | RING.BACK-UP | 0.002 kg. |
| 15. | 707-36-16410 | [1] | PISTON | |
| 16. | 707-44-16180 | [1] | RING.PISTON | 0.13 kg. |
| 17. | 07156-01620 | [1] | RING.WEAR | 0.046 kg. |
| 18. | 707-40-18070 | [2] | SPACER | 1.02 kg. |
| 19. | 01010-61240 | [6] | BOLT | 0.052 kg. |
| 20. | 707-51-90640 | [1] | RING.BUFFER | 0.05 kg. |
| 707-99-64130 | [1] | SERVICE KIT | 0.322 kg. |
Hydraulic Seal installation requirements:
1. the hydraulic sealing gaskets and flange sealing surface should be clean
2. hydraulic sealing gasket diameter should be smaller than flange seal face outside and inside diameter should be slightly bigger than a pipe inside diameter
3. Sealing gasket pre-tightening force should not exceed the design rules
4. sealing asbestos gasket compression, it is best to use the torque wrench
5. Installing a sealing gasket, should be in order, in turn, tighten the nut
6.if there is any leakage, must be installed after antihypertensive treatment to replace or adjust the sealing gasket
